Baumer O200.SL-GW1J.72CV/F160_H006 Photoelectric Sensor
The Banner O200.SL-GW1J.72CV/F160_H006 Photoelectric Sensor offers a 8 mm diameter, Pulsed red laser diode light source, Push-pull output circuit, and Cable 4 pin, 2 m connection type. Manufactured by Banner under the Banner Photoelectric Sensor category, this model belongs to the O200 Series.
| Brand | Banner |
| Product Type | Photoelectric Sensor |
| Model Number | O200.SL-GW1J.72CV/F160_H006 |
Baumer O200.SL-GW1J.72CV/F160_H006 Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Light barrier |
| Background position Sde | 25 β¦ 180 mm |
| Scanning range Sa | 90% ... 85% Sde |
| Smallest object recognizable typ. | 0.5 mm |
| Power on indication | LED green |
| Alignment / soiled lens indicator | Flashing output indicator |
| Output indicator | LED yellow |
| Sensing distance adjustment | Teach-in and IO-Link |
| Suppression of reciprocal influence | Yes |
| Alignment optical axis | < 1,5Β° |
| Light source | Pulsed red laser diode |
| Wave length | 680 nm |
| Response time / release time | < 0.25 ms (High Speed Mode) |
| Voltage supply range +Vs | 10 β¦ 30 VDC |
| Current consumption max. (no load) | 20 mA (@ 10 VDC) |
| Current consumption typ. | 10 mA (@ 24 VDC) |
| Voltage drop Vd | <2 VDC |
| Output function | Light / dark operate |
| Output circuit | Push-pull |
| Output current | 50 mA |
| Width / diameter | 8 mm |
| Height / length | 25.1 mm |
| Depth | 15.8 mm |
| Design | Rectangular |
| Mechanical mounting | Threaded sleeves M3 (stainless steel) |
| Housing material | Plastic (ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Cable 4 pin, 2 m |
| Cable characteristics | PVC / PVC 4 x 0.08 mmΒ² |
| Protection class | IP 67 |
| Operating temperature | -20 β¦ +50 Β°C |
Call us for Baumer Sensor In Rectangular Design O200.SL-GW1J.72CV/F160_H006 part no: 11230779 at the best rates. Technical Attributes of O200.SL-GW1J.72CV/F160_H006, 11230779 are Light barrier, Type offering superior precision and reliability. This sensor features a scanning range (Sa) 90% ... 85% Sde with adjustable sensing distance Teach-in and IO-Link. It operates using a Pulsed red laser diode light source with a wave length of 680 nm. The voltage supply range is 10 β¦ 30 VDC, with a current consumption of 20 mA (@ 10 VDC). The voltage drop (Vd) is less than <2 VDC, with Light / dark operate output functions. The output circuit is Push-pull, and the output current is rated at 50 mA. With a width of 8 mm and a height of 25.1 mm, the housing is made of durable Plastic (ASA, PMMA). This sensor is equipped with a Cable 4 pin, 2 m connection. Unlock Exclusive Pricing with a Quote for your requirement of Baumer Sensor In Rectangular Design. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
