Baumer O200.RP-GW1J.72NV Photoelectric Sensor
The Baumer O200.RP-GW1J.72NV Photoelectric Sensor offers a Rectangular design, 4 m nominal range, 10 … 30 VDC supply voltage, Push-pull output, and Flylead connector M8 4 pin, L=200 mm connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the O200 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Product | O200.RP-GW1J.72NV |
Baumer O200.RP-GW1J.72NV Photoelectric Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Type | Retro-reflective sensor |
| Light source | Pulsed PinPoint LED |
| Actual range Sb | 3 m |
| Nominal range Sn | 4 m |
| Smallest object recognizable typ. | 4 mm (FTAR 013A000) |
| Polarization filter | Yes |
| Alignment / soiled lens indicator | Flashing output indicator |
| Output indicator | LED yellow |
| Power on indication | LED green |
| Sensitivity adjustment | Teach-in and IO-Link |
| Wave length | 644 nm |
| Suppression of reciprocal influence | Yes |
| Alignment optical axis | < 1,5° |
| Response time / release time | < 0.25 ms |
| Voltage supply range +Vs | 10 … 30 VDC |
| Current consumption max. (no load) | 40 mA (@ 10 VDC) |
| Current consumption typ. | 16 mA (@ 24 VDC) |
| Voltage drop Vd | <2 VDC |
| Output function | Light / dark operate |
| Output circuit | Push-pull |
| Output current | 50 mA |
| Width / diameter | 8 mm |
| Height / length | 25.1 mm |
| Depth | 15.8 mm |
| Design | Rectangular |
| Mechanical mounting | Sleeve smooth (stainless steel) |
| Housing material | Plastic (ASA, PMMA) |
| Front (optics) | PMMA |
| Connection types | Flylead connector M8 4 pin, L=200 mm |
| Cable characteristics | PVC / PVC 4 x 0.08 mm² |
| Operating temperature | -25 … +50 °C |
| Protection class | IP 67 |
Call us for Baumer Retro-Reflective Sensor For Industrial Use O200.RP-GW1J.72NV part no: 11210277 at the best rates. Technical Attributes of O200.RP-GW1J.72NV, 11210277 are Retro-reflective sensor designed for precision detection with an actual range of 3 m and a nominal range of 4 m. The sensor features a Pulsed PinPoint LED light source with a wavelength of 644 nm, ensuring accurate performance with a response time of less than < 0.25 ms. It operates within a voltage supply range of 10 … 30 VDC, supporting both Light / dark operate functions through a Push-pull output circuit capable of handling up to 50 mA of output current. Measuring 8 mm in width and 25.1 mm in height, the sensor’s compact Rectangular design is housed in durable Plastic (ASA, PMMA) materials, making it ideal for industrial environments. The sensor connects via a Flylead connector M8 4 pin, L=200 mm for reliable integration. Pricing with a Quote for your requirement of Baumer Retro-Reflective Sensor For Industrial Use. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
