Baumer MY-COM C100/80: Precision Mechanical Switches
Technical Specifications of Baumer Precision Mechanical Switches MY-COM C100/80:
| Repeat accuracy | 0.001 mm |
| DC voltage max. | 15 VDC |
| Connection types | Cable, 80 cm |
| Operating temperature | -20 … +75 °C |
Baumer Precision Mechanical Switches MY-COM C100/80 Technical Specifications
| Specification | Value |
|---|---|
| Repeat accuracy | 0.001 mm |
| Activating force | 100 cN |
| Mech. pre-run / overrun | - / 1,5 mm approx. |
| Measurement type | Contact with medium |
| Direction of approach | Frontal |
| DC voltage max. | 15 VDC |
| Switch. current DC max. | 2 mA |
| AC voltage max. | 24 VAC |
| Switch. current AC max. | 2 mA |
| Output circuit | Break function (NC) mechanical |
| Activating pin | Zirconium oxide ZrO2 |
| Housing material | Brass nickel plated |
| Dimension | 8 mm |
| Design | Rectangular |
| Housing length | 20 mm |
| Connection types | Cable, 80 cm |
| Operating temperature | -20 … +75 °C |
| Protection class | IP 50 |
