MIR10: Baumer Incremental Encoders Without Bearings
Technical Specifications of Baumer Incremental Encoders Without Bearings MIR10:
| Spec | Value |
|---|---|
| Voltage supply | 5 VDC ±5 % |
| Sensing method | Magnetic |
| Connection | Cable 2 m, Cable 0.3 m with connector M12 |
🛠️ Get Quotes Instantly from Baumer Vendors
Baumer Incremental Encoders Without Bearings MIR10 Technical Specifications:
| Specification | Value |
|---|---|
| Voltage supply | 5 VDC ±5 % |
| Consumption typ. | 30 mA (w/o load) |
| Initializing time | ≤ 50 ms after power on (see general informations) |
| Sensing method | Magnetic |
| Output stages | HTL/push-pull, TTL/RS422 |
| Output signals | A+, B+, R+, A-, B-, R- |
| Output frequency | ≤40 kHz (10-fold interpolation), ≤80 kHz (20-fold interpolation), ≤350 kHz (32-/64-fold interpolation) |
| Shaft type | ø6...43.5 mm (through hollow shaft) |
| Protection EN 60529 | IP 66, IP 67 |
| Operating speed | ≤10000 rpm (50 and 64 poles), ≤20000 rpm (32 poles) |
| Working distance | 0.1 … 0.6 mm (axial/radial) |
| Material | Housing: zinc diecast, plated |
| Operating temperature | -40...+85 °C |
| Relative humidity | EN 60068-2-78:2010, EN 60068-2-30:2005, 93 % condensation permitted |
| Resistance | EN 60068-2-6, Vibration 30 g, 10-2000 Hz, EN 60068-2-27, Shock 500 g, 6 ms |
| Weight approx. | 130 g |
| Connection | Cable 2 m, Cable 0.3 m with connector M12 |
Obtain a Quote for Baumer Incremental Encoders Without Bearings MIR10 with exclusive offers. Core System Specifications of MIR10, feature voltage supply of 5 VDC ±5 % and output stages including HTL/push-pull, TTL/RS422 options. The encoders have an IP 66, IP 67 protection rating according to EN 60529, ensuring robust performance in harsh environments. The working distance is ,0.1 … 0.6 mm (axial/radial). The Housing: zinc diecast, plated. Connection options include Cable 2 m, Cable 0.3 m with connector M12 for flexible installation. Operating temperature ranges from -40...+85 °C making these encoders suitable for extreme conditions. Initiate Your Journey with a Quote for your requirement of Baumer Incremental Encoders Without Bearings. Trust in our ability to provide more advantageous pricing and dedicated support beyond other Suppliers & Traders.
