Baumer MAGRES EAM580-B - PROFINET Rotary Encoder
The Baumer MAGRES EAM580-B - PROFINET Rotary Encoder offers a Multiturn function, Magnetic sensing method, ø10...15 mm (blind hollow shaft) shaft type, and Flange connector 3xM12 connection. Manufactured by Baumer under the Baumer Rotary Encoder category, this model belongs to the EAL580-B Series.
| Brand | Sick |
| Product Type | Rotary Encoders |
| Model Number | MAGRES EAM580-B - PROFINET |
Baumer MAGRES EAM580-B - PROFINET Rotary Encoder – Technical Specifications
| Specification | Value |
|---|---|
| Voltage supply | 10...30 VDC |
| Interface | PROFINET IO |
| Function | Multiturn |
| Absolute accuracy | ±0.15 ° (+20 ±15 °C), ±0.25 ° (-40...+85 °C) |
| Sensing method | Magnetic |
| Status indicator | 4x LED integrated in housing |
| Size (flange) | ø58 mm |
| Shaft type | ø10...15 mm (blind hollow shaft) |
| Protection EN 60529 | IP 65 (without shaft seal), IP 67 (with shaft seal) |
| Operating speed | ≤6000 rpm |
| Starting torque | ≤2 Ncm (+20 °C, IP 65), ≤2.5 Ncm (+20 °C, IP 67) |
| Material | Housing: steel zinc-coated, Flange: aluminium, Hollow shaft: stainless steel |
| Operating temperature | -40...+85 °C (see general information) |
| Relative humidity | 95 % |
| Resistance | EN 60068-2-6, Vibration 30 g, 10-2000 Hz, EN 60068-2-27, Shock 250 g, 6 ms |
| Weight approx. | 360 g |
| Connection | Flange connector 3xM12 |
Obtain a Quote for Baumer Magnetic Absolute Encoder MAGRES EAM580-B - PROFINET at economical prices. Specifications Overview for MAGRES EAM580-B - PROFINET, reveals voltage supply of 10...30 VDC. These encoders feature the PROFINET IO interface, Multiturn functionality, and Magnetic sensing methods for accurate performance. The flange size is ø58 mm, making them suitable for various industrial applications. The operating speed reaches up to ≤6000 rpm operations, ensuring reliable functionality in demanding environments. The Housing: steel zinc-coated, Flange: aluminium, Hollow shaft: stainless steel, provides robust protection. The connection is facilitated by Flange connector 3xM12, ensuring secure and efficient data transmission. Take the First Step with a Quote for your requirement of Baumer Magnetic Absolute Encoder. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
