Home Brands Baumer Industrial Camera LXG-40M Baumer LXG-40M Industrial Camera The Baumer LXG-40M Industrial Camera offers a 54.4 dB dynamic range, Global shutter , C-mount , and ams (CMOSIS) CMV4000 V3 connection. Manufactured by Baumer under the Baumer Industrial Camera category, this model belongs to the CX Series.
Brand Baumer Product Type Industrial Camera Model Number LXG-40M
Baumer LXG-40M Industrial Camera – Technical Specifications Specification Value Sensor ams (CMOSIS) CMV4000 V3 Mono/Color Mono Sensor type 1″ CMOS Shutter type Global shutter Resolution 2048 × 2048 px Pixel size 5.5 × 5.5 µm Exposure time 0.03 … 1000 ms Dark noise 15.05 e- Saturation capacity 8326 e- Dynamic range 54.4 dB Signal-to-noise ratio 39.2 dB Image formats, interface frame rate max. Full Frame, 2048 × 2048 px, max. 59 fps, Binning 2×2, 1024 × 1024 px, max. 180 fps, Binning 1×2, 2048 × 1024 px, max. 118 fps, Binning 2×1, 1024 × 2048 px, max. 81 fps Image formats, aquisition frame rate max. (Burst Mode) Full Frame, 2048 × 2048 px, max. 180 fps Pixel formats Mono8, Mono10, Mono10 Packed Analog controls Gain (0 … 12 dB), Offset (0 … 63 LSB 10 Bit) Color models Mono Internal image buffer 512 MB Process interface M8 / 8 pins Power supply via M8 / 8 pins Lens mount C-mount Width 60 mm Height 60 mm Depth 52.4 mm Weight ≤ 340 g Material housing: aluminum Voltage supply range +Vs 12 … 24 V DC (external power supply), 36 … 57 V DC (Power over Ethernet) Power consumption Approx. 6.2 W @ 24 VDC, Approx. 5.2 W @ 48 VDC (PoE) Flash memory size 128 kB Operating temperature #ERROR! Humidity 10 … 90 % (non-condensing) Protection class IP 40
