Home Brands Baumer Industrial Camera LXC-500C Baumer LXC-500C Industrial Camera The Baumer LXC-500C Industrial Camera offers a 63.2 dB dynamic range, Global shutter , M58-mount (F-mount, M42, C-mount via adapter) , and ams (CMOSIS) CMV50000 connection. Manufactured by Baumer under the Baumer Industrial Camera category, this model belongs to the CX Series.
Brand Baumer Product Type Industrial Camera Model Number LXC-500C
Baumer LXC-500C Industrial Camera – Technical Specifications Specification Value Sensor ams (CMOSIS) CMV50000 Mono/Color Color Sensor type 35 mm CMOS Shutter type Global shutter Resolution 7920 × 6004 px Pixel size 4.6 × 4.6 µm Exposure time 0.1 … 10000 ms Dark noise 8.23 e- Saturation capacity 12734 e- Dynamic range 63.2 dB Signal-to-noise ratio 41 dB Image formats, interface frame rate max. Full Frame, 7920 × 6004 px, max. 15 fps Pixel formats BayerBG8, BayerBG10, BayerBG12 Analog controls Gain (0 … 23,5 dB), Offset (0 … 255 LSB 12 Bit) Color models Raw Bayer Color processing NA Internal image buffer 512 MB Process interface M8 / 8 pins Power supply via M8 / 8 pins Lens mount M58-mount (F-mount, M42, C-mount via adapter) Width 60 mm Height 60 mm Depth 43.05 mm Weight ≤ 235 g (M58-mount) Material housing: aluminum Voltage supply range +Vs 12 … 24 V DC (external power supply), 38 … 57 V (PoCL) Power consumption Approx. 10 W @ 24 VDC (sequential readout), Approx. 10 W @ 12 VDC (PoCL) Flash memory size 32 Mbit Operating temperature #ERROR! Humidity 10 … 90 % (non-condensing) Protection class IP 40
