Baumer IWRP 16I8704/S14C Proximity Sensor
The Baumer IWRP 16I8704/S14C Proximity Sensor offers a Cylindrical threaded design, 0 … 4 mm sensing distance, Current output output, Flush mounting type, and Connector M12 5 pin connection. Manufactured by Baumer under the Baumer Proximity Sensor category, this model belongs to the IF Series.
| Brand | Baumer |
| Product Type | Proximity Sensor |
| Model Number | IWRP 16I8704/S14C |
Baumer IWRP 16I8704/S14C Proximity Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Mounting type | Flush |
| Measuring distance Sd | 0 … 4 mm |
| Resolution | < 0.005 mm (stat.), < 0.005 mm (dynam.) |
| Repeat accuracy | 0.01 mm |
| Linearity error | ± 120 µm (S = 0 ... 4 mm) |
| Temperature drift | ± 10 % (Full Scale) |
| Response time (factory characteristic) | < 1 ms |
| Voltage supply range +Vs | 8 … 36 VDC |
| Current consumption max. (no load) | 15 mA |
| Output circuit | Current output |
| Output signal | 4 ... 20 mA |
| Load resistance | < 50 Ohm/V * Vs - 250 Ohm > 500 Ohm (Vs = 30 … 36 VDC) |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Design | Cylindrical threaded |
| Material (sensing face) | Ceramic |
| Housing material | Stainless steel |
| Dimension | 16 mm |
| Housing length | 61 mm |
| Connection types | Connector M12 5 pin |
| Tightening torque max. | 30 Nm |
| Operating temperature | -25 … +75 °C (Vs = 8 ... 30 VDC), -25 … +60 °C (Vs = 8 ... 36 VDC) |
| Protection class | IP 68/67 (sensing face/sensor) |
Obtain a Quote for Baumer Inductive Distance Sensor IWRP 16I8704/S14C Article No: 11167164 at economical prices. Specifications Overview for IWRP 16I8704/S14C, 11167164 reveals Flush mounting type with a measuring distance of 0 … 4 mm. It delivers < 0.005 mm (stat.), < 0.005 mm (dynam.) resolution, ensuring repeat accuracy of 0.01 mm. The linearity error is ± 120 µm (S = 0 ... 4 mm), with a temperature drift of ± 10 % (Full Scale). The factory-set response time is < 1 ms, making it ideal for high-speed applications. It operates within an 8 … 36 VDC voltage supply range, consuming only 15 mA. The Cylindrical threaded design includes a Ceramic sensing face and an Stainless steel housing for durability. The compact structure has an 16 mm dimension and an 61 mm housing length. It connects via a Connector M12 5 pin and operates in temperatures between -25 … +75 °C (Vs = 8 ... 30 VDC), -25 … +60 °C (Vs = 8 ... 36 VDC) with IP 68/67 (sensing face/sensor) protection. Take the First Step with a Quote for your requirement of Inductive Distance Sensor. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
