Baumer IWFM 12U9501/O1 Proximity Sensor
The Baumer IWFM 12U9501/O1 Proximity Sensor offers a Rectangular design, 1 … 2 mm sensing distance, Voltage output output, Flush mounting type, and Cable, L=2 m connection. Manufactured by Baumer under the Baumer Proximity Sensor category, this model belongs to the IF Series.
| Brand | Baumer |
| Product Type | Proximity Sensor |
| Model Number | IWFM 12U9501/O1 |
Baumer IWFM 12U9501/O1 Proximity Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Mounting type | Flush |
| Measuring distance Sd | 1 … 2 mm |
| Resolution | - |
| Repeat accuracy | 0.02 mm |
| Linearity error | ± 80 µm |
| Temperature drift | - |
| Response time (factory characteristic) | - |
| Voltage supply range +Vs | 15 … 30 VDC |
| Current consumption max. (no load) | 20 mA |
| Output circuit | Voltage output |
| Output signal | 1 ... 9 VDC |
| Load resistance | > 1000 Ohm |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Design | Rectangular |
| Material (sensing face) | PBT |
| Housing material | Brass nickel plated |
| Dimension | 12 mm |
| Housing length | 55 mm |
| Connection types | Cable, L=2 m |
| Tightening torque max. | - |
| Operating temperature | 0 … +60 °C |
| Protection class | IP 67 |
Obtain a Quote for Baumer Inductive Distance Sensor IWFM 12U9501/O1 Article No: 10237474 at economical prices. Specifications Overview for IWFM 12U9501/O1, 10237474 reveals Flush mounting type with a measuring distance of 1 … 2 mm. It delivers - resolution, ensuring repeat accuracy of 0.02 mm. The linearity error is ± 80 µm, with a temperature drift of -. The factory-set response time is -, making it ideal for high-speed applications. It operates within an 15 … 30 VDC voltage supply range, consuming only 20 mA. The Rectangular design includes a PBT sensing face and an Brass nickel plated housing for durability. The compact structure has an 12 mm dimension and an 55 mm housing length. It connects via a Cable, L=2 m and operates in temperatures between 0 … +60 °C with IP 67 protection. Take the First Step with a Quote for your requirement of Inductive Distance Sensor. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
