Baumer ITD 40 A 4 Y79 Rotary Encoder
The Baumer ITD 40 A 4 Y79 Rotary Encoder offers a ø80 mm size, 200 … 2048 ppr, Optical method, and Cable 1 m connection. Manufactured by Baumer under the Baumer Rotary Encoder category, this model belongs to the EIL580 Series.
| Voltage supply | 5 VDC ±5 %, 8...30 VDC |
| Sensing method | Optical |
| Size (flange) | ø80 mm |
| Connection | Cable 1 m |
Baumer ITD 40 A 4 Y79 Rotary Encoder – Technical Specifications
| Specification | Value |
|---|---|
| Voltage supply | 5 VDC ±5 %, 8...30 VDC |
| Consumption w/o load | ≤100 mA |
| Pulses per revolution | 200 … 2048 |
| Reference signal | Zero pulse, width 90° |
| Sensing method | Optical |
| Output frequency | ≤120 kHz |
| Output signals | A, B, N + inverted |
| Output stages | TTL linedriver (short-circuit proof), HTL push-pull (short-circuit proof) |
| Size (flange) | ø80 mm |
| Shaft type | ø20...27 mm (through hollow shaft) |
| Protection EN 60529 | IP 65 |
| Operating speed | ≤5000 rpm, ≤3000 rpm IP 65 (>70 °C) |
| Starting torque | ≤0.025 Nm (+20 °C) |
| Material | Housing: aluminium, black, powder-coated, Shaft: stainless steel |
| Operating temperature | -20...+70 °C, -20...+100 °C |
| Relative humidity | 90 % non-condensing |
| Resistance | EN 60068-2-6, Vibration 10 g, 55-2000 Hz, EN 60068-2-27, Shock 100 g, 6 ms |
| Connection | Cable 1 m |
| Weight approx. | 600 g |
Get A Quote for Baumer 2048 Pulses Per Revolution Encoder ITD 40 A 4 Y79 at the best price. Here are the brief Technical Specifications of ITD 40 A 4 Y79, are voltage supply of 5 VDC ±5 %, 8...30 VDC and a low power consumption of ≤100 mA without load. These encoders use Optical sensing for accurate measurement and provide output frequencies of ≤120 kHz. The available output stages include TTL linedriver (short-circuit proof), HTL push-pull (short-circuit proof). The encoders feature a ø80 mm flange size and operate at speeds of up to ≤5000 rpm, ≤3000 rpm IP 65 (>70 °C). The Housing: aluminium, black, powder-coated, Shaft: stainless steel. Connection options include Cable 1 m. The approximate weight is 600 g. It's Time to get a Quote for your requirement of Baumer 2048 Pulses Per Revolution Encoder. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
