Baumer IR18.P12S-F50.NO1Z.7BCV Proximity Sensor
The Baumer IR18.P12S-F50.NO1Z.7BCV Proximity Sensor offers a Cylindrical threaded design, 12 mm sensing distance, NPN make function (NO) output, Flush mounting type, and Cable, L=2 m connection. Manufactured by Baumer under the Baumer Proximity Sensor category, this model belongs to the IR Series.
| Nominal sensing distance Sn | 12 mm |
| Mounting type | Flush |
| Output circuit | NPN make function (NO) |
Baumer IR18.P12S-F50.NO1Z.7BCV Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Mounting type | Flush |
| Nominal sensing distance Sn | 12 mm |
| Hysteresis | 3 β¦ 20 % of Sr |
| Output indicator | LED red |
| Switching frequency | 400 Hz |
| Voltage supply range +Vs | 6 β¦ 36 VDC |
| Current consumption max. (no load) | 10 mA |
| Output circuit | NPN make function (NO) |
| Voltage drop Vd | <2 VDC |
| Output current | 100 mA |
| Design | Cylindrical threaded |
| Material (sensing face) | PBT |
| Housing material | Brass nickel plated |
| Dimension | 18 mm |
| Housing length | 50 mm |
| Connection types | Cable, L=2 m |
| Tightening torque max. | 40 Nm |
| Operating temperature | -25 β¦ +75 Β°C |
| Protection class | IP 67 |
Talk to Our Engineer for Baumer Switch Red LED Indicator IR18.P12S-F50.NO1Z.7BCV part no: 11148844 with exclusive offers. Core System Specifications of IR18.P12S-F50.NO1Z.7BCV, 11148844 are Flush Mounting type. The sensor features a nominal sensing distance of 12 mm and a high switching frequency of 400 Hz, ensuring rapid response times. It operates within a voltage supply range of 6 β¦ 36 VDC, with a low current consumption of just 10 mA. The output circuit is a NPN make function (NO), capable of handling up to 100 mA of output current. The sensor's design includes a robust Cylindrical threaded housing made from high-grade Brass nickel plated, providing durability in demanding environments. With a compact dimension of 18 mm, it fits seamlessly into tight spaces. The sensor is equipped with a reliable Cable, L=2 m. Don't Miss Out on a Quote for your requirement of Baumer Switch Red LED Indicator. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
