Baumer IR18.D08F-F60.UA1E.7BO Proximity Sensor
The Baumer IR18.D08F-F60.UA1E.7BO Proximity Sensor offers a Cylindrical threaded design, 0 β¦ 8 mm sensing distance, Voltage output output, Flush mounting type, and Connector M12 connection. Manufactured by Baumer under the Baumer Proximity Sensor category, this model belongs to the IF Series.
| Brand | Baumer |
| Product Type | Proximity Sensor |
| Model Number | IR18.D08F-F60.UA1E.7BO |
Baumer IR18.D08F-F60.UA1E.7BO Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Mounting type | Flush |
| Measuring distance Sd | 0 β¦ 8 mm |
| Resolution | < 0.02 mm (stat.), < 0.03 mm (dynam.) |
| Repeat accuracy | 0.03 mm |
| Linearity error | Β± 70 Β΅m |
| Temperature drift | Β± 3 % (Full Scale: S = 0 ... 6 mm), Β± 5 % (Full Scale: S = 0 ... 8 mm) |
| Response time (factory characteristic) | < 15 ms |
| Voltage supply range +Vs | 12 β¦ 36 VDC |
| Current consumption max. (no load) | 15 mA |
| Output circuit | Voltage output |
| Output signal | 0 ... 10 VDC |
| Load resistance | > 4000 Ohm |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Design | Cylindrical threaded |
| Material (sensing face) | PBT |
| Housing material | Brass nickel plated |
| Dimension | 18 mm |
| Housing length | 60 mm |
| Connection types | Connector M12 |
| Tightening torque max. | 40 Nm |
| Operating temperature | -25 β¦ +75 Β°C |
| Protection class | IP 67 |
Get A Quote for Baumer Inductive Distance Sensor IR18.D08F-F60.UA1E.7BO Article No: 11170540 at the best price. Here are the brief Technical Specifications of IR18.D08F-F60.UA1E.7BO, 11170540 are Flush mounting type with a measuring distance of 0 β¦ 8 mm. It delivers < 0.02 mm (stat.), < 0.03 mm (dynam.) resolution, ensuring repeat accuracy of 0.03 mm. The linearity error is Β± 70 Β΅m, with a temperature drift of Β± 3 % (Full Scale: S = 0 ... 6 mm), Β± 5 % (Full Scale: S = 0 ... 8 mm). The factory-set response time is < 15 ms, making it ideal for high-speed applications. It operates within an 12 β¦ 36 VDC voltage supply range, consuming only 15 mA. The Cylindrical threaded design includes a PBT sensing face and an Brass nickel plated housing for durability. The compact structure has an 18 mm dimension and an 60 mm housing length. It connects via a Connector M12 and operates in temperatures between -25 β¦ +75 Β°C with IP 67 protection. It's Time to get a Quote for your requirement of Inductive Distance Sensor. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
