Baumer IR12.D03K-F60.UA1E.7FO/B015 Proximity Sensor
The Baumer IR12.D03K-F60.UA1E.7FO/B015 Proximity Sensor offers a Cylindrical threaded design, 2.75 … 3 mm sensing distance, Voltage output output, Flush mounting type, and Connector M12 connection. Manufactured by Baumer under the Baumer Proximity Sensor category, this model belongs to the IR12 Series.
| Brand | Baumer |
| Product Type | Proximity Sensor |
| Model Number | IR12.D03K-F60.UA1E.7FO/B015 |
Baumer IR12.D03K-F60.UA1E.7FO/B015 Proximity Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Mounting type | Flush |
| Measuring distance Sd | 2.75 … 3 mm |
| Resolution | < 0.00025 mm (stat.), < 0.0005 mm (dynam.) |
| Repeat accuracy | 0.001 mm |
| Linearity error | ± 5 µm |
| Temperature drift | ± 4 % (Full Scale: +10 ... +30 °C), ± 12 % (Full Scale: -10 ... +60 °C) |
| Response time (factory characteristic) | < 3 ms |
| Voltage supply range +Vs | 12 … 30 VDC |
| Current consumption max. (no load) | 15 mA |
| Output circuit | Voltage output |
| Output signal | 0 ... 10 VDC |
| Load resistance | > 4000 Ohm |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Design | Cylindrical threaded |
| Material (sensing face) | Ceramic |
| Housing material | Steel nickel plated |
| Dimension | 12 mm |
| Housing length | 60 mm |
| Connection types | Connector M12 |
| Tightening torque max. | 15 Nm |
| Operating temperature | -10 … +60 °C |
| Protection class | IP 67 |
Give Us a Call for Baumer Inductive Distance Sensor IR12.D03K-F60.UA1E.7FO/B015 Article No: 11158153 at the lowest pricing. In-depth Technical Analysis of IR12.D03K-F60.UA1E.7FO/B015, 11158153 feature Flush mounting type with a measuring distance of 2.75 … 3 mm. It delivers < 0.00025 mm (stat.), < 0.0005 mm (dynam.) resolution, ensuring repeat accuracy of 0.001 mm. The linearity error is ± 5 µm, with a temperature drift of ± 4 % (Full Scale: +10 ... +30 °C), ± 12 % (Full Scale: -10 ... +60 °C). The factory-set response time is < 3 ms, making it ideal for high-speed applications. It operates within an 12 … 30 VDC voltage supply range, consuming only 15 mA. The Cylindrical threaded design includes a Ceramic sensing face and an Steel nickel plated housing for durability. The compact structure has an 12 mm dimension and an 60 mm housing length. It connects via a Connector M12 and operates in temperatures between -10 … +60 °C with IP 67 protection. Elevate Your Project with a Quote for your requirement of Inductive Distance Sensor. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
