Baumer IFRR 08P33T1/S14L-9 Proximity Sensor
The Baumer IFRR 08P33T1/S14L-9 Proximity Sensor offers a Cylindrical threaded design, 3 mm sensing distance, PNP break function (NC) output, Non-flush mounting type, and Connector M12 connection. Manufactured by Baumer under the Baumer Proximity Sensor category, this model belongs to the IF Series.
| Nominal sensing distance Sn | 3 mm |
| Mounting type | Non-flush |
| Output circuit | PNP break function (NC) |
Baumer IFRR 08P33T1/S14L-9 Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Mounting type | Non-flush |
| Nominal sensing distance Sn | 3 mm |
| Hysteresis | 2 β¦ 15 % of Sr |
| Output indicator | LED red |
| Switching frequency | 3 kHz |
| Voltage supply range +Vs | 6 β¦ 30 VDC |
| Current consumption max. (no load) | 10 mA |
| Output circuit | PNP break function (NC) |
| Voltage drop Vd | <2 VDC |
| Output current | 200 mA |
| Design | Cylindrical threaded |
| Material (sensing face) | LCP |
| Housing material | Stainless steel 1.4404 (V4A); LSR |
| Dimension | 8 mm |
| Housing length | 55 mm |
| Connection types | Connector M12 |
| Tightening torque max. | 10 Nm (Front: 7 Nm) |
| Operating temperature | -40 β¦ +80 Β°C |
| Protection class | IP 68/69K & proTect+ |
Call us for Baumer 3 mm Non-flush Inductive Switch IFRR 08P33T1/S14L-9 part no: 11016167 at the best rates. Technical Attributes of IFRR 08P33T1/S14L-9, 11016167 are Non-flush Mounting type. The sensor features a nominal sensing distance of 3 mm and a high switching frequency of 3 kHz, ensuring rapid response times. It operates within a voltage supply range of 6 β¦ 30 VDC, with a low current consumption of just 10 mA. The output circuit is a PNP break function (NC), capable of handling up to 200 mA of output current. The sensor's design includes a robust Cylindrical threaded housing made from high-grade Stainless steel 1.4404 (V4A); LSR, providing durability in demanding environments. With a compact dimension of 8 mm, it fits seamlessly into tight spaces. The sensor is equipped with a reliable Connector M12. Unlock Exclusive Pricing with a Quote for your requirement of Baumer 3 mm Non-flush Inductive Switch. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
