Baumer IFRM 04P35A5/Q Proximity Sensor
The Baumer IFRM 04P35A5/Q Proximity Sensor offers a Cylindrical smooth design, 1 mm scanning range, PNP break function (NC) output, Flush mounting type, and Wires, 0,5 m connection. Manufactured by Baumer under the Baumer Proximity Sensor category, this model belongs to the IF Series.
| Brand | Baumer |
| Product Type | Proximity Sensor |
| Product | IFRM 04P35A5/Q |
Baumer IFRM 04P35A5/Q Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Mounting type | Flush |
| Nominal sensing distance Sn | 1 mm |
| Hysteresis | 2 β¦ 20 % of Sr |
| Switching frequency | 5 kHz |
| Voltage supply range +Vs | 6 β¦ 30 VDC |
| Current consumption max. (no load) | 12 mA |
| Output circuit | PNP break function (NC) |
| Voltage drop Vd | <2 VDC |
| Output current | 200 mA |
| Design | Cylindrical smooth |
| Housing material | Stainless steel |
| Dimension | 4 mm |
| Housing length | 15 mm |
| Connection types | Wires, 0,5 m |
| Operating temperature | -25 β¦ +75 Β°C |
| Protection class | IP 67 |
Mail Us for Baumer Wires, 0,5m Connection Inductive Switch IFRM 04P35A5/Q part no: 10144457 at the lowest pricing. Technical Specs Summary of IFRM 04P35A5/Q, 10144457 are Flush Mounting type. This sensor features a nominal sensing distance of 1 mm and a switching frequency of 5 kHz, making it ideal for high-speed applications and the sensor operates within a voltage supply range of 6 β¦ 30 VDC, with a maximum current consumption of 12 mA. The output circuit is an PNP break function (NC). The sensor's Cylindrical smooth design is crafted from high-quality Stainless steel with LSR for durability. It has a compact dimension of 4 mm and is equipped with a reliable Wires, 0,5 m for easy integration. Navigate Your Needs with a Quote for your requirement of Baumer Wires, 0,5m Connection Inductive Switch. We excel in offering more cost-effective and supportive solutions than other Competitors.
