Baumer IFRM 04N35A3/S35L Proximity Sensor
The Baumer IFRM 04N35A3/S35L Proximity Sensor offers a Cylindrical smooth design, 1 mm scanning range, NPN break function (NC) output, Flush mounting type, and Connector M8 connection. Manufactured by Baumer under the Baumer Proximity Sensor category, this model belongs to the IF Series.
| Brand | Baumer |
| Product Type | Proximity Sensor |
| Product | IFRM 04N35A3/S35L |
Baumer IFRM 04N35A3/S35L Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Mounting type | Flush |
| Nominal sensing distance Sn | 1 mm |
| Hysteresis | 2 β¦ 20 % of Sr |
| Output indicator | 3 port LED red |
| Switching frequency | 5 kHz |
| Voltage supply range +Vs | 6 β¦ 30 VDC |
| Current consumption max. (no load) | 12 mA |
| Output circuit | NPN break function (NC) |
| Voltage drop Vd | <2 VDC |
| Output current | 200 mA |
| Design | Cylindrical smooth |
| Housing material | Stainless steel |
| Dimension | 4 mm |
| Housing length | 36 mm |
| Connection types | Connector M8 |
| Operating temperature | -25 β¦ +75 Β°C |
| Protection class | IP 67 |
Call us for Baumer NC (Normally Closed) Proximity Switches IFRM 04N35A3/S35L part no: 10143516 at the best rates. Technical Attributes of IFRM 04N35A3/S35L, 10143516 are Flush Mounting type. This sensor features a nominal sensing distance of 1 mm and a switching frequency of 5 kHz, making it ideal for high-speed applications. The output indicator is an 3 port LED red light, and the sensor operates within a voltage supply range of 6 β¦ 30 VDC, with a maximum current consumption of 12 mA. The output circuit is an NPN break function (NC). The sensor's Cylindrical smooth design is crafted from high-quality Stainless steel with LSR for durability. It has a compact dimension of 4 mm and is equipped with a reliable Connector M8 for easy integration. Unlock Exclusive Pricing with a Quote for your requirement of Baumer NC (Normally Closed) Proximity Switches. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
