Baumer IFFM 12P37A3/S05L Proximity Sensor
The Baumer IFFM 12P37A3/S05L Proximity Sensor offers a Rectangular design, 4 mm sensing distance, PNP break function (NC) output, Flush mounting type, and Connector M5 connection. Manufactured by Baumer under the Baumer Proximity Sensor category, this model belongs to the IF Series.
| Mounting Type | Flush |
| Nominal sensing distance Sn | 4 mm |
| Output Circuit | PNP break function (NC) |
| Connection Types | Connector M5 |
Baumer IFFM 12P37A3/S05L Proximity Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Mounting type | Flush |
| Nominal sensing distance Sn | 4 mm |
| Hysteresis | 3 β¦ 20 % of Sr |
| Output indicator | LED red |
| Switching frequency | 2 kHz |
| Voltage supply range +Vs | 10 β¦ 30 VDC |
| Current consumption max. (no load) | 10 mA |
| Output circuit | PNP break function (NC) |
| Voltage drop Vd | <2 VDC |
| Output current | 200 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Design | Rectangular |
| Material (sensing face) | PBT |
| Housing material | Brass nickel plated |
| Dimension | 12 mm |
| Housing length | 23.5 mm |
| Connection types | Connector M5 |
| Operating temperature | -25 β¦ +75 Β°C |
| Protection class | IP 67 |
Give Us a Call for Baumer 2 kHz Switching Frequency Miniature Sensors IFFM 12P37A3/S05L part no: 10147638 at the lowest pricing. In-depth Technical Analysis of IFFM 12P37A3/S05L, 10147638 feature Flush Mount Sensor, designed for precision applications with a 4 mm nominal sensing distance. The sensor features a LED red output indicator and operates at a fast switching frequency of 2 kHz ensuring rapid response times. The voltage supply range is from 10 β¦ 30 VDC and the output circuit uses an PNP break function (NC), capable of handling an output current of up to 200 mA. Its Rectangular design and durable Brass nickel plated (Polyamide) Housing material ensure reliability in industrial environments. The sensor has a compact housing length of 23.5 mm and overall dimensions of 12 mm. Equipped with an AB550 connection, it operates within a temperature range of -25 β¦ +75 Β°C. Elevate Your Project with a Quote for your requirement of Baumer 2 kHz Switching Frequency Miniature Sensors. Our promise: More affordable pricing and more personalized support than other Distributors & Dealers.
