Baumer IF08.D03L-Q25.GP1I.7VNU Proximity Sensor
The Baumer IF08.D03L-Q25.GP1I.7VNU Proximity Sensor offers a Rectangular design, 0 … 3 mm sensing distance, PNP, Push-pull, IO-Link output, Quasi-flush mounting type, and Flylead connector PUR M8, L=200 mm connection. Manufactured by Baumer under the Baumer Proximity Sensor category, this model belongs to the IF Series.
| Brand | Baumer |
| Product Type | Proximity Sensor |
| Model Number | IF08.D03L-Q25.GP1I.7VNU |
Baumer IF08.D03L-Q25.GP1I.7VNU Proximity Sensor – Technical Specifications
| Specification | Value |
|---|---|
| Mounting type | Quasi-flush |
| Measuring distance Sd | 0 … 3 mm |
| Resolution | < 0.005 mm (High Accuracy Mode) |
| Repeat accuracy | 0.01 mm |
| Linearity error | ± 10 µm (S = 0 ... 2 mm), ± 90 µm (S = 0 ... 3 mm) |
| Temperature drift | ± 2 % (Full Scale: S = 0 ... 2 mm), ± 6 % (Full Scale: S = 0 ... 3 mm) |
| Response time (factory characteristic) | < 1 ms |
| Voltage supply range +Vs | 8 … 30 VDC |
| Current consumption max. (no load) | 15 mA |
| Output circuit | PNP, Push-pull, IO-Link |
| Output signal | - |
| Load resistance | - |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Design | Rectangular |
| Material (sensing face) | PBT |
| Housing material | Stainless steel |
| Dimension | 8 mm |
| Housing length | 24.6 mm |
| Connection types | Flylead connector PUR M8, L=200 mm |
| Tightening torque max. | 0.8 Nm |
| Operating temperature | -20 … +70 °C |
| Protection class | IP 67 |
Obtain a Quote for Baumer Inductive Distance Sensor IF08.D03L-Q25.GP1I.7VNU Article No: 11244232 at economical prices. Specifications Overview for IF08.D03L-Q25.GP1I.7VNU, 11244232 reveals Quasi-flush mounting type with a measuring distance of 0 … 3 mm. It delivers < 0.005 mm (High Accuracy Mode) resolution, ensuring repeat accuracy of 0.01 mm. The linearity error is ± 10 µm (S = 0 ... 2 mm), ± 90 µm (S = 0 ... 3 mm), with a temperature drift of ± 2 % (Full Scale: S = 0 ... 2 mm), ± 6 % (Full Scale: S = 0 ... 3 mm). The factory-set response time is < 1 ms, making it ideal for high-speed applications. It operates within an 8 … 30 VDC voltage supply range, consuming only 15 mA. The Rectangular design includes a PBT sensing face and an Stainless steel housing for durability. The compact structure has an 8 mm dimension and an 24.6 mm housing length. It connects via a Flylead connector PUR M8, L=200 mm and operates in temperatures between -20 … +70 °C with IP 67 protection. Take the First Step with a Quote for your requirement of Inductive Distance Sensor. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
