Baumer HOG 86 + FSL Rotary Encoder
The Baumer HOG 86 + FSL Rotary Encoder offers a ø105 mm size, 500 … 5000 ppr, Optical method, and 2x terminal box, 3x terminal box (with option M) connection. Manufactured by Baumer under the Baumer Rotary Encoder category, this model belongs to the Heavyduty Incremental Encoder.
| Sensing Method | Optical |
| Switching Outputs | 1 output, speed control |
| Connection | 2x terminal box, 3x terminal box (with option M) |
Baumer HOG 86 + FSL Rotary Encoder – Technical Specifications
| Specification | Value |
|---|---|
| Voltage supply | 9...30 VDC, 5 VDC ±5 % |
| Consumption w/o load | ≤100 mA |
| Pulses per revolution | 500 … 5000 |
| Phase shift | 90 ° ±20° |
| Duty cycle | 45…55 %, 40…60 % (>3072 pulses) |
| Reference signal | Zero pulse, width 90° |
| Sensing method | Optical |
| Output signals | K1, K2, K0 + inverted, Error output (option EMS) |
| Output stages | HTL-P (power linedriver), TTL/RS422 |
| Switching accuracy | ± 4 % (Δn = 2 rpm/s);, 20 % (Δn = 1500 rpm/s) |
| Switching outputs | 1 output, speed control |
| Output switching capacity | ≤6 A / 230 VAC, ≤1 A / 125 VDC, (EAC: <50 VAC / 75 VDC) |
| Switching hysteresis | 40 % of switching speed |
| Size (flange) | ø105 mm |
| Shaft type | ø16 mm (blind hollow shaft), ø17 mm (cone shaft 1:10) |
| Admitted shaft load | ≤350 N axial, ≤450 N radial |
| Protection EN 60529 | IP 66 |
| Operating torque typ. | 6 Ncm |
| Rotor moment of inertia | 200 gcm² |
| Material | Housing: aluminium, coated, Shaft: stainless steel |
| Operating temperature | -40...+100 °C, -25...+100 °C (>3072 pulses) |
| Resistance | IEC 60068-2-6, Vibration 5 g, 10-2000 Hz, IEC 60068-2-27, Shock 50 g, 11 ms |
| Corrosion protection | IEC 60068-2-52 Salt mist, for ambient conditions C4 according to ISO 12944-2 |
| Connection | 2x terminal box, 3x terminal box (with option M) |
| Weight approx. | 1.9 kg, 2 kg (with option M) |
Mail Us for your needs in Baumer Industrial Incremental Encoder HOG 86 + FSL part no: 11077087 with budget-friendly prices. The Main Technical Parameters of HOG 86 + FSL, 11077087 inludce voltage supply of 9...30 VDC, 5 VDC ±5 % and pulses per revolution ranging from 500 … 5000. The encoders provide a phase shift of 90 ° ±20° and a duty cycle of 45…55 %, 40…60 % (>3072 pulses), with a Zero pulse, width 90°. Using Optical sensing technology, the encoders offer output signals including K1, K2, K0 + inverted, Error output (option EMS). The available output stages are HTL-P (power linedriver), TTL/RS422, ensuring versatile performance. The encoders come in an ø105 mm flange size and operate at speeds of up to -40...+100 °C, -25...+100 °C (>3072 pulses). Constructed with a durable Housing: aluminium, coated, Shaft: stainless steel, they offer connections via 2x terminal box, 3x terminal box (with option M). Customize Your Experience with a Quote for your requirement of Baumer Industrial Incremental Encoder. Experience the difference with our competitive pricing and superior support over other Suppliers.
