Baumer HOG 86 + FSL Rotary Encoder
The Baumer HOG 86 + FSL Rotary Encoder offers a ΓΈ105 mm size, 500 β¦ 5000 ppr, Optical method, and 2x terminal box, 3x terminal box (with option M) connection. Manufactured by Baumer under the Baumer Rotary Encoder category, this model belongs to the Heavyduty Encoders.
| Voltage Supply | 9...30 VDC, 5 VDC Β±5 % |
| Sensing Method | Optical |
| Size (flange) | ΓΈ105 mm |
| Connection | 2x terminal box, 3x terminal box (with option M) |
Baumer HOG 86 + FSL Rotary Encoder β Technical Specifications
| Specification | Value |
|---|---|
| Voltage supply | 9...30 VDC, 5 VDC Β±5 % |
| Consumption w/o load | β€100 mA |
| Pulses per revolution | 500 β¦ 5000 |
| Phase shift | 90 Β° Β±20Β° |
| Duty cycle | 45β¦55 %, 40β¦60 % (>3072 pulses) |
| Reference signal | Zero pulse, width 90Β° |
| Output frequency | β€120 kHz, β€300 kHz (on request) |
| Output signals | K1, K2, K0 + inverted, Error output (option EMS) |
| Output stages | HTL-P (power linedriver), TTL/RS422 |
| Sensing method | Optical |
| Shaft insulation | Suitable up to 2.8 kV |
| Transmission length | β€350 m at 100 kHz (HTL-P), β€550 m at 100 kHz (TTL) |
| Switching accuracy | Β± 4 % (Ξn = 2 rpm/s);, 20 % (Ξn = 1500 rpm/s) |
| Switching deviation | β€3 % (cw-ccw rotation) |
| Switching hysteresis | 40 % of switching speed |
| Switching outputs | 1 output, speed control |
| Output switching capacity | β€6 A / 230 VAC, β€1 A / 125 VDC, (EAC: <50 VAC / 75 VDC) |
| Minimum switching current | 50 mA |
| Size (flange) | ΓΈ105 mm |
| Shaft type | ΓΈ16 mm (blind hollow shaft), ΓΈ17 mm (cone shaft 1:10) |
| Admitted shaft load | β€350 N axial, β€450 N radial |
| Protection EN 60529 | IP 66 |
| Speed (n) | β€1.25 Β· ns |
| Range of switching speed (ns) | 850...4500 rpm (Ξn = 2 rpm/s) |
| Operating torque typ. | 6 Ncm |
| Rotor moment of inertia | 200 gcmΒ² |
| Material | Housing: aluminium, coated, Shaft: stainless steel |
| Operating temperature | -40...+100 Β°C, -25...+100 Β°C (>3072 pulses) |
| Resistance | IEC 60068-2-6, Vibration 5 g, 10-2000 Hz, IEC 60068-2-27, Shock 50 g, 11 ms |
| Corrosion protection | IEC 60068-2-52 Salt mist, for ambient conditions C4 according to ISO 12944-2 |
| Connection | 2x terminal box, 3x terminal box (with option M) |
| Weight approx. | 1.9 kg, 2 kg (with option M) |
Get A Quote for Baumer Encoder With Integrated Centrifugal Switch HOG 86 + FSL at the best price. Here are the brief Technical Specifications of N/A, are voltage supply of 9...30 VDC, 5 VDC Β±5 %, and consumption of β€100 mA without load. These encoders offer a range of pulses per revolution from 500 β¦ 5000 providing versatility in precision. The output stages include HTL-P (power linedriver), TTL/RS422 for flexible integration. The encoders come in a robust ΓΈ105 mm flange size and can handle shaft loads of up to β€350 N axial, β€450 N radial. With an operating torque of 6 Ncm, they are designed for smooth performance. The Housing: aluminium, coated, Shaft: stainless steel and operates in temperatures ranging from -40...+100 Β°C, -25...+100 Β°C (>3072 pulses). Connection options include 2x terminal box, 3x terminal box (with option M). It's Time to get a Quote for your requirement of Baumer Encoder With Integrated Centrifugal Switch. We guarantee unmatched pricing and unparalleled support compared to other Distributors.
