Baumer HOG 16 + DSL Rotary Encoder
The Baumer HOG 16 + DSL Rotary Encoder offers a ΓΈ158 mm size, 512 β¦ 2500 ppr, Optical method, and 2x terminal box, 3x terminal box (with option M) connection. Manufactured by Baumer under the Baumer Rotary Encoder category, this model belongs to the Heavyduty Encoders.
| Voltage Supply | With DSL.R: 15...30 VDC, With DSL.E: 9...30 VDC |
| Sensing Method | Optical |
| Size (flange) | ΓΈ158 mm |
| Connection | 2x terminal box, 3x terminal box (with option M) |
Baumer HOG 16 + DSL Rotary Encoder β Technical Specifications
| Specification | Value |
|---|---|
| Voltage supply | With DSL.R: 15...30 VDC, With DSL.E: 9...30 VDC |
| Consumption w/o load | β€200 mA |
| Pulses per revolution | 512 β¦ 2500 |
| Phase shift | 90 Β° Β±20Β° |
| Duty cycle | 40β¦60 % |
| Reference signal | Zero pulse, width 90Β° |
| Output frequency | β€120 kHz |
| Output signals | K1, K2, K0 + inverted |
| Output stages | HTL, TTL/RS422 |
| Sensing method | Optical |
| Switching accuracy | Β± 2 % (or Digit) |
| Switching outputs | With DSL.R: 3 outputs, speed control, With DSL.E: 2 outputs, speed control and 1 control output |
| Output switching capacity | With DSL.R: 12 VDC; β€40 mA, With DSL.E: 5...230 VAC/VDC; 5...250 mA, (EAC: <50 VAC / 75 VDC) |
| Size (flange) | ΓΈ158 mm |
| Shaft type | ΓΈ20...50 mm (through hollow shaft) |
| Admitted shaft load | β€450 N axial, β€600 N radial |
| Protection EN 60529 | IP 66 |
| Speed (n) | β€6000 rpm |
| Range of switching speed (ns) | Pulses = 512: Β±16...6000 rpm, Pulses = 1024: Β±8...6000 rpm, Pulses = 2000: Β±5...3600 rpm, Pulses = 2048: Β±4...3500 rpm, Pulses = 2500: Β±3...2900 rpm |
| Rotor moment of inertia | 4.9 kgcmΒ² |
| Material | Housing: aluminium, Shaft: stainless steel |
| Operating temperature | -20...+85 Β°C |
| Resistance | IEC 60068-2-6, Vibration 15 g, 10-2000 Hz, IEC 60068-2-27, Shock 300 g, 6 ms |
| Corrosion protection | IEC 60068-2-52 Salt mist, for ambient conditions C4 according to ISO 12944-2 |
| Connection | 2x terminal box, 3x terminal box (with option M) |
| Weight approx. | 4 kg, 5 kg (with option M) |
| Switching delay time | β€40 ms |
Obtain a Quote for Baumer Encoder Resolution Precision HOG 16 + DSL at economical prices. Specifications Overview for N/A, reveals voltage supply of With DSL.R: 15...30 VDC, With DSL.E: 9...30 VDC, and consumption of β€200 mA without load. These encoders offer a range of pulses per revolution from 512 β¦ 2500 providing versatility in precision. The output stages include HTL, TTL/RS422 for flexible integration. The encoders come in a robust ΓΈ158 mm flange size and can handle shaft loads of up to β€450 N axial, β€600 N radial. With an operating torque of , they are designed for smooth performance. The Housing: aluminium, Shaft: stainless steel and operates in temperatures ranging from -20...+85 Β°C. Connection options include 2x terminal box, 3x terminal box (with option M). Take the First Step with a Quote for your requirement of Baumer Encoder Resolution Precision. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
