Baumer HMG10P-T - EtherCAT Rotary Encoder
The Baumer HMG10P-T - EtherCAT Rotary Encoder offers a ø105 mm size, ø16...20 mm (through hollow shaft) type, Magnetic method, and Bus connecting box, Terminal box incremental connection. Manufactured by Baumer under the Baumer Rotary Encoder category, this model belongs to the Heavyduty Absolute Encoder.
| Brand | Baumer |
| Product Type | Encoder |
| Product | HMG10P-T - EtherCAT |
Baumer HMG10P-T - EtherCAT Rotary Encoder – Technical Specifications
| Specification | Value |
|---|---|
| Voltage supply | 10...30 VDC |
| Short-circuit proof | Yes |
| Consumption w/o load | ≤200 mA |
| Initializing time | ≤500 ms after power on |
| Interface | EtherCAT |
| Function | Multiturn |
| Transmission rate | 100 MBaud |
| Device adress | Automatic address designation |
| Steps per revolution | 8192 / 13 bit |
| Number of revolutions | 65536 / 16 bit |
| Additional outputs | Square-wave TTL/HTL,TTL/RS422 |
| Sensing method | Magnetic |
| Programmable parameters | Bus system: see bus features, Additional output (number of pulses), switch-off and switch-on speeds |
| Diagnostic function | Position or parameter error |
| Status indicator | DUO-LED and LEDs link/activity in bus connecting box 4 LEDs in device back side |
| Switching accuracy | ± 2 % (or 1 Digit) |
| Switching outputs | 1 output (Open collector, solid state relay on request) |
| Output switching capacity | 30 VDC; ≤100 mA |
| Switching delay time | ≤20 ms |
| Size (flange) | ø105 mm |
| Shaft type | ø16...20 mm (through hollow shaft) |
| Flange | Support plate, 360° freely positionable |
| Protection EN 60529 | IP 66 / IP 67 |
| Operating speed | ≤6000 rpm |
| Range of switching speed | ns (off) = ±2...6000 rpm, factory setting 6000 rpm |
| Operating torque typ. | 10 Ncm |
| Rotor moment of inertia | 950 gcm² |
| Admitted shaft load | ≤450 N axial, ≤650 N radial |
| Material | Housing: aluminium alloy, Shaft: stainless steel |
| Corrosion protection | IEC 60068-2-52 Salt mist, for ambient conditions CX (C5-M) according to ISO 12944-2 |
| Operating temperature | -40...+85 °C |
| Relative humidity | 95 % non-condensing |
| Resistance | IEC 60068-2-6, Vibration 30 g, 10-2000 Hz, IEC 60068-2-27, Shock 400 g, 1 ms |
| Weight approx. | 2.2 kg (depending on version) |
| Connection | Bus connecting box, Terminal box incremental |
Talk to Our Engineer for Baumer Encoder With EtherCAT Protocol HMG10P-T - EtherCAT with exclusive offers. Core System Specifications of HMG10P-T - EtherCAT, are voltage supply of 10...30 VDC and consumption of ≤200 mA without load. These encoders feature a fast initializing time of ≤500 ms after power on, ensuring quick setup. The Magnetic sensing method guarantees precise performance, with 1 output (Open collector, solid state relay on request). The output switching capacity is 30 VDC; ≤100 mA. The operating speed reaches up to ≤6000 rpm, with a switching speed range of ns (off) = ±2...6000 rpm, factory setting 6000 rpm. The Housing: aluminium alloy, Shaft: stainless steel shaft for added strength. Connections include a Bus connecting box, Terminal box incremental outputs. Don't Miss Out on a Quote for your requirement of Baumer Encoder With EtherCAT Protocol. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
