Baumer HG 6 Rotary Encoder
The Baumer HG 6 Rotary Encoder offers a ø58 mm size, 100 … 512 ppr, Optical method, and Connecting terminal connection. Manufactured by Baumer under the Baumer Rotary Encoder category, this model belongs to the Heavyduty Incremental Encoder.
| Sensing Method | Optical |
| Connection | Connecting terminal |
Baumer HG 6 Rotary Encoder – Technical Specifications
| Specification | Value |
|---|---|
| Voltage supply | 9...26 VDC, 5 VDC ±5 % |
| Consumption w/o load | ≤100 mA |
| Pulses per revolution | 100 … 512 |
| Phase shift | 90 ° ±20° |
| Duty cycle | 40…60 % |
| Reference signal | Zero pulse, width 90° |
| Sensing method | Optical |
| Output signals | K1, K2, K0 + inverted |
| Output stages | HTL, TTL/RS422 |
| Size (flange) | ø58 mm |
| Shaft type | ø12...16 mm (blind hollow shaft) |
| Protection EN 60529 | IP 55 (≤12000 U/min), IP 23 (≤30000 rpm) |
| Operating speed | ≤12000 rpm, ≤30000 rpm (option) |
| Rotor moment of inertia | 18 gcm² |
| Material | Housing: aluminium, Shaft: stainless steel |
| Operating temperature | -20...+85 °C |
| Resistance | IEC 60068-2-6, Vibration 10 g, 10-2000 Hz, IEC 60068-2-27, Shock 100 g, 6 ms |
| Connection | Connecting terminal |
| Weight approx. | 180 g |
Call us for Baumer 512 Pulses Per Revolution Incremental Encoder HG 6 part no: at the best rates. Technical Attributes of HG 6, are voltage supply of 9...26 VDC, 5 VDC ±5 % and pulses per revolution ranging from 100 … 512. The encoders provide a phase shift of 90 ° ±20° and a duty cycle of 40…60 %, with a Zero pulse, width 90°. Using Optical sensing technology, the encoders offer output signals including K1, K2, K0 + inverted. The available output stages are HTL, TTL/RS422, ensuring versatile performance. The encoders come in an ø58 mm flange size and operate at speeds of up to -20...+85 °C. Constructed with a durable Housing: aluminium, Shaft: stainless steel, they offer connections via Connecting terminal. Unlock Exclusive Pricing with a Quote for your requirement of Baumer 512 Pulses Per Revolution Incremental Encoder. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
