During technical comparisons, FPDM-16P3921-S14 appears alongside Baumer Proximity Sensor, Baumer Sensors and PLC Repair so engineers assess signal types, ingress protection, and ambient tolerances accurately.
Baumer FPDM 16P3921/S14 Photoelectric Sensor
The Baumer FPDM 16P3921/S14 Photoelectric Sensor offers a Rectangular design, 7.2 m nominal range, 10 β¦ 30 VDC supply voltage, PNP output, and Connector M12 4 pin connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the O200 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Product | FPDM 16P3921/S14 |
Baumer FPDM 16P3921/S14 Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Retro-reflective sensor |
| Light source | Pulsed red LED |
| Actual range Sb | 6 m |
| Nominal range Sn | 7.2 m |
| Polarization filter | Yes |
| Sensitivity adjustment | Teach-in |
| Wave length | 660 nm |
| Response time / release time | < 2.5 ms |
| Voltage supply range +Vs | 10 β¦ 30 VDC |
| Current consumption max. (no load) | 50 mA |
| Current consumption typ. | 40 mA |
| Voltage drop Vd | <1.8 VDC |
| Output function | Dark operate |
| Output circuit | PNP |
| Output current | 200 mA |
| Width / diameter | 15.4 mm |
| Height / length | 50 mm |
| Depth | 50 mm |
| Design | Rectangular |
| Housing material | Die-cast zinc |
| Front (optics) | PMMA |
| Connection types | Connector M12 4 pin |
| Operating temperature | -25 β¦ +65 Β°C |
| Protection class | IP 67 |
Talk to Our Engineer for Baumer Industrial Sensor With M12 Connector FPDM 16P3921/S14 part no: 10122958 with exclusive offers. Core System Specifications of FPDM 16P3921/S14, 10122958 are Retro-reflective sensor designed for precision detection with an actual range of 6 m and a nominal range of 7.2 m. The sensor features a Pulsed red LED light source with a wavelength of 660 nm, ensuring accurate performance with a response time of less than < 2.5 ms. It operates within a voltage supply range of 10 β¦ 30 VDC, supporting both Dark operate functions through a PNP output circuit capable of handling up to 200 mA of output current. Measuring 15.4 mm in width and 50 mm in height, the sensorβs compact Rectangular design is housed in durable Die-cast zinc materials, making it ideal for industrial environments. The sensor connects via a Connector M12 4 pin for reliable integration. Don't Miss Out on a Quote for your requirement of Baumer Industrial Sensor With M12 Connector. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
