Baumer FODK 23P90Y0: Level Sensors
Technical Specifications of Baumer FODK 23P90Y0 10146555:
| Voltage supply range +Vs | 12 … 24 VDC |
| Output circuit | PNP |
| Output current | 50 mA |
Baumer Level Sensors FODK 23P90Y0 Technical Specifications
| Specification | Value |
|---|---|
| Sensitivity adjustment | No |
| Output indicator | LED orange |
| Measurement type | Contact with medium |
| Voltage supply range +Vs | 12 … 24 VDC |
| Current consumption max. (no load) | 30 mA |
| Output circuit | PNP |
| Output current | 50 mA |
| Voltage drop Vd | <1 VDC |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Design | Rectangular |
| Housing material | PFA / PVC |
| Depth | 37.2 mm |
| Connection types | Cable 3 pin, 2 m |
| Operating temperature | -25 … +50 °C |
| Protection class | IP 67 |
| Light indicator | LED green |
| Width / diameter | 23 mm |
| Height / length | 10.5 mm |
