Baumer FEDM 12P5101 Photoelectric Sensor
The Baumer FEDM 12P5101 Photoelectric Sensor offers a Rectangular design, 7.5 m nominal range, Receiver, PNP output, and Cable 4 pin, 2 m connection. Manufactured by Baumer under the Baumer Photoelectric Sensor category, this model belongs to the O200 Series.
| Brand | Baumer |
| Product Type | Photoelectric Sensor |
| Model Number | FEDM 12P5101 |
Baumer FEDM 12P5101 Photoelectric Sensor β Technical Specifications
| Specification | Value |
|---|---|
| Type | Through beam sensor |
| Emitter / receiver | Receiver |
| Actual range Sb | 6 m |
| Nominal range Sn | 7.5 m |
| Alignment / soiled lens indicator | Flashing light indicator |
| Sensitivity adjustment | No |
| Response time / release time | < 1 ms |
| Voltage supply range +Vs | 10 β¦ 30 VDC |
| Current consumption max. (no load) | 17 mA |
| Current consumption typ. | 17 mA |
| Voltage drop Vd | <1.8 VDC |
| Output function | Light / dark operate |
| Output circuit | PNP |
| Output current | 100 mA |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Width / diameter | 12.4 mm |
| Height / length | 35 mm |
| Depth | 35 mm |
| Design | Rectangular |
| Housing material | Die-cast zinc |
| Front (optics) | PMMA |
| Connection types | Cable 4 pin, 2 m |
| Operating temperature | -25 β¦ +65 Β°C |
| Protection class | IP 67 |
| Light indicator | LED yellow |
Obtain a Quote for Baumer 2 m Cable 4-pin Through-beam Sensor FEDM 12P5101 part no: 10234248 at economical prices. Specifications Overview for FEDM 12P5101, 10234248 reveals Through beam sensor Model Type designed for precise object detection with a nominal range of 7.5 m. This sensor operates on a voltage supply range of 10 β¦ 30 VDC, with a maximum current consumption of 17 mA and a typical consumption of 17 mA. The compact Rectangular design features dimensions of 12.4 mm in width, 35 mm in height, and 35 mm in depth, ensuring easy installation in various industrial environments. The housing is made from durable Die-cast zinc offering robustness for demanding applications. The sensor connects via a Cable 4 pin, 2 m making it suitable for seamless integration into your system. With a Receiver. Take the First Step with a Quote for your requirement of Baumer 2 m Cable 4-pin Through-beam Sensor. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
