Baumer DST55R-28.100.TI1.A5 , 11707525: Miniaturized Strain Sensor
Baumer DST55R-28.100.TI1.A5 Strain Sensor
| Brand | Baumer |
| Product Type | Strain Sensor |
| Model Number | DST55R-28.100.TI1.A5 |
Baumer Miniaturized Strain Sensor DST55R-28.100.TI1.A5 11707525 Technical Specifications
| Specification | Value |
|---|---|
| Nominal strain | 0 ... 100 μm/m |
| Non-linearity | < 0.5 % |
| Repeatability | < 0.1 % |
| Mechanical mounting | 2 x M8 screws |
| Dimensions | 40 mm x 21 mm x 71 mm |
| Weight | 330 g |
| Compensated for thermal expansion coefficient | 11.1 * 10-6 1/K |
| Electrical connection | M12, 5 pin, male |
| Operating temperature range | -40 ... 85 °C |
| Storage temperature range | -40 ... 85 °C |
| Protection class EN 60529, ISO20653 | IP 68, 168h @ 1m H2O, IP 69K, ProTect+ |
| Output signal | 4 ... 20 mA |
| Signal polarity positive | Tension |
| Bridge resistance | 350 Ω |
| Supply voltage | 18 ... 33 VDC |
Get A Quote for Baumer Miniaturized Strain Sensor DST55R-28.100.TI1.A5 Article No 11707525 at unbeatable prices. Detailed Specifications of DST55R-28.100.TI1.A5, 11707525 feature nominal strain of 0 ... 100 μm/m, making it ideal for applications requiring fine strain measurements. It features a compact body with 40 mm x 21 mm x 71 mm dimensions and is mechanically mounted using 2 x M8 screws for secure installation. With a fatigue strength of over , it ensures exceptional durability in demanding operations. The sensor provides a stiffness rating of 80 N @ 100 μm/m, guaranteeing stability under load. The sensor body is constructed from corrosion-resistant 1.7225, chemically nickel plated for rugged environments. It operates on a supply voltage range of 18 ... 33 VDC, with an operating and storage temperature range of -40 ... 85 °C and -40 ... 85 °C. Match Your Needs with a Quote for your requirement of Miniaturized Strain Sensor DST55R-28.100.TI1.A5. Our pricing and support are unrivaled, especially when compared to other Distributors.
