Baumer DST53-A202I , 11244544: Miniaturized Strain Sensor
Baumer DST53-A202I Strain Sensor
| Brand | Baumer |
| Product Type | Strain Sensor |
| Model Number | DST53-A202I |
Baumer Miniaturized Strain Sensor DST53-A202I 11244544 Technical Specifications
| Specification | Value |
|---|---|
| Nominal strain | 0 ... 2000 μm/m |
| Non-linearity | < 0.3 % |
| Repeatability | < 0.1 % |
| Mechanical mounting | 4 x M6 screws |
| Dimensions | 26 mm x 17 mm x 70 mm |
| Weight | 135 g |
| Compensated for thermal expansion coefficient | 11.1 * 10-6 1/K |
| Electrical connection | M12, 5 pin, male |
| Operating temperature range | -40 °C ... 85 °C |
| Storage temperature range | -40 °C ... 85 °C |
| Protection class EN 60529, ISO20653 | IP 65 |
| Output signal | 4 ... 20 mA, IO-Link |
| Signal polarity positive | Tension |
| Bridge resistance | 350 Ω |
| Supply voltage | 18 ... 30 VDC |
Talk to Our Engineer for Baumer Miniaturized Strain Sensor DST53-A202I Article No 11244544 with exclusive offers. Core System Specifications ofDST53-A202I, 11244544 feature nominal strain of 0 ... 2000 μm/m, making it ideal for applications requiring fine strain measurements. It features a compact body with 26 mm x 17 mm x 70 mm dimensions and is mechanically mounted using 4 x M6 screws for secure installation. With a fatigue strength of over >10 Mio cycles at 0...100% FS, it ensures exceptional durability in demanding operations. The sensor provides a stiffness rating of 130 N @ 2000 µm/m, guaranteeing stability under load. The sensor body is constructed from corrosion-resistant 1.7225, chemically nickel plated for rugged environments. It operates on a supply voltage range of 18 ... 30 VDC, with an operating and storage temperature range of -40 °C ... 85 °C and -40 °C ... 85 °C. Don't Miss Out on a Quote for your requirement of Miniaturized Strain Sensor DST53-A202I. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
