Baumer DST20-A500P , 11231317: Miniaturized Strain Sensor
Baumer DST20-A500P Strain Sensor
| Brand | Baumer |
| Product Type | Strain Sensor |
| Model Number | DST20-A500P |
Baumer Miniaturized Strain Sensor DST20-A500P 11231317 Technical Specifications
| Specification | Value |
|---|---|
| Nominal strain | 0 ... 500 μm/m |
| Non-linearity | < 0.5 % |
| Repeatability | < 0.1 % |
| Mechanical mounting | 2 x M4 screws |
| Dimensions | 12 mm x 10 mm x 28 mm |
| Weight | 13 g |
| Compensated for thermal expansion coefficient | 10.9 * 10-6 1/K |
| Electrical connection | M5, 4 pin, male |
| Operating temperature range | -40 ... 85 °C |
| Storage temperature range | -40 ... 85 °C |
| Protection class EN 60529, ISO20653 | IP 65 |
| Output signal | mV/V |
| Signal polarity positive | Tension |
| Nominal sensitivity | 1.0 mV/V |
| Bridge resistance | 350 Ω |
| Supply voltage | 0.5 VDC ... 7 VDC |
Get A Quote for Baumer Miniaturized Strain Sensor DST20-A500P Article No 11231317 at the best price. Here are the brief Technical Specifications ofDST20-A500P, 11231317 feature nominal strain of 0 ... 500 μm/m, making it ideal for applications requiring fine strain measurements. It features a compact body with 12 mm x 10 mm x 28 mm dimensions and is mechanically mounted using 2 x M4 screws for secure installation. With a fatigue strength of over >10 Mio cycles at 0...100% FS, it ensures exceptional durability in demanding operations. The sensor provides a stiffness rating of 200 N @ 500 μm/m, guaranteeing stability under load. The sensor body is constructed from corrosion-resistant Stainless steel, 1.4542 for rugged environments. It operates on a supply voltage range of 0.5 VDC ... 7 VDC, with an operating and storage temperature range of -40 ... 85 °C and -40 ... 85 °C. It's Time to get a Quote for your requirement of Miniaturized Strain Sensor DST20-A500P. Choose us for unparalleled pricing and support over other Dealers & Distributors.
