Baumer CombiTemp TFRN Temperature Measurement
The Baumer CombiTemp TFRN Temperature Measurement offers a 20 … 3000 mm sensor length. Manufactured by Baumer under the Baumer Temperature Measurement category, this model belongs to the VS Series.
| Brand | Baumer |
| Product Type | Temperature Measurement |
| Model Number | CombiTemp TFRN |
Baumer CombiTemp TFRN Temperature Measurement – Technical Specifications
| Specification | Value |
|---|---|
| Degree of protection (EN 60529) | IP67, IP69K , with appropriate cable |
| Humidity | < 98 % RH , condensing |
| Vibration (sinusoidal) (EN 60068-2-6) | 1.6 mm p-p (2 … 25 Hz), 4 g (25 … 100 Hz), 1 octave / min. |
| EMC | EN 61000-6-2, EN 61000-6-3, EN 61326-1 |
| Explosion protection | ATEX II 1 G Ex ia IIC T6...T4, IECEx Ex ia IIC T6...T4, ATEX II 3 G Ex ec IIC T5...T4, Ex ia Simple apparatus, gas and dust |
| Process temperature | Refer to section "Operating conditions" |
| Pt100 accuracy class (EN 60751) | B (± 0.3 °C at 0 °C), ± (0.3 + 0.005 × t)°C, A (± 0.15 °C at 0 °C), ± (0.15 + 0.002 × t)°C, 1/3 B (± 0.1 °C at 0 °C), ± 1/3 × (0.3 + 0.005 × t)°C, 1/6 B (± 0.05 °C at 0 °C), ± 1/6 × (0.3 + 0.005 × t)°C |
| Process pressure | Refer to section "Operating conditions" |
| Sensor length | 20 … 3000 mm |
| Sensor tube material | AISI 316L (1.4404) |
| Surface roughness wetted parts | Ra ≤ 1.6 µm |
| Without transmitter | 1 x Pt100, 2-wire, 1 x Pt100, 4-wire, 2 x Pt100, 2-wire |
| Cable | M16 plastic, cable dia. 5 ... 10 mm, M16 stainless steel, cable dia. 5 ... 9 mm, M20 plastic, cable dia. 8 ... 13 mm, M20 stainless steel, cable dia. 9 ... 13 mm |
| Thermal response time, T50 | < 1.5 s , Ø4 mm, < 6.1 s , Ø6 mm, < 7.6 s , Ø8 mm |
| With transmitter | 4 … 20 mA , 2-wire, 4 … 20 mA , 2-wire + HART® |
Talk to Our Engineer for Baumer Temperature Measurement CombiTemp TFRN with exclusive offers. Core System Specifications of CombiTemp TFRN,are rated IP67, IP69K , with appropriate cable, providing excellent protection against dust and water. It operates reliably in humidity levels below < 98 % RH , condensing, making it suitable for demanding environments. Designed to withstand harsh conditions, enduring 1.6 mm p-p (2 … 25 Hz), 4 g (25 … 100 Hz), 1 octave / min.. The sensor length is 20 … 3000 mm, ensuring a compact and efficient design. Built with AISI 316L (1.4404) stainless steel, the sensor tube offers superior corrosion resistance for industrial applications. The surface roughness of wetted parts is Ra ≤ 1.6 µm, ensuring optimal performance in precision measurement tasks. Don't Miss Out on a Quote for your requirement of Temperature Measurement. Count on us for more economical pricing and more reliable support than other Dealers & Distributors.
