Baumer CFAK 12P1103: Capacitive Proximity Sensors
Technical Specifications of Baumer Capacitive Proximity Sensor CFAK 12P1103:
| Nominal sensing distance Sn | 0.5 mm |
| Mounting type | Non-flush |
| Output circuit | PNP make function (NO) |
| Connection types | Cable, L=2 m |
Baumer Capacitive Proximity Sensors CFAK 12P1103 Technical Specifications
| Specification | Value |
|---|---|
| Nominal sensing distance Sn | 0.5 mm |
| Mounting type | Non-flush |
| GND electrode | No |
| Temperature drift | Β± 20 % |
| Sensitivity adjustment | No |
| Output indicator | LED yellow |
| Measurement type | Contact with medium |
| Detection of non-conductive media | No |
| Voltage supply range +Vs | 10 β¦ 30 VDC |
| Current consumption max. (no load) | 12 mA |
| Output circuit | PNP make function (NO) |
| Output current | 200 mA |
| Voltage drop Vd | <2.5 VDC |
| Switching frequency | 15 Hz |
| Short circuit protection | Yes |
| Reverse polarity protection | Yes |
| Design | Cylindrical threaded |
| Housing material | PBT |
| Dimension | 12 mm |
| Housing length | 39 mm |
| Connection types | Cable, L=2 m |
| Operating temperature | 0 β¦ +70 Β°C |
| Protection class | IP 67 |
