acA1600-20uc: 106220 - Basler Area Scan Camera with Color
Technical Specifications of Basler Area Scan Camera with Color acA1600-20uc 106220:
| Sensor | ICX274 |
| Sensor size | 7.16 mm × 5.44 mm |
| Mount | C-mount |
| Cable Length | 10 m |
Basler Area Scan Camera with Color acA1600-20uc, 106220 Technical Specifications:
| Specification | Value |
|---|---|
| Product Family | ace Classic |
| Products Line | Standard |
| Camera Category | Area Scan Camera |
| Sensor Vendor | Sony |
| Sensor | ICX274 |
| Shutter | Global Shutter |
| Sensor Format | 2/3" |
| Sensor Diagonal | 8.99 mm |
| Sensor Type | CCD |
| Sensor Size | 7.16 mm × 5.44 mm |
| Resolution (H x V) | 1626 px × 1234 px |
| Resolution | 2 MP |
| Pixel Size (H x V) | 4.4 μm × 4.4 μm |
| Frame rate | 20 fps |
| Mono/Color | Color |
| Spectrum | Visible |
| Interface | USB 3.0 |
| Image Data Interface | USB 3.0, nominal max. 5 Gbit/s (SuperSpeed) |
| Pixel Bit Depth | 12 bits |
| Exposure Control | hardware trigger, programmable via the camera API |
| Digital Input | 1 |
| Power Supply | Via USB 3.0 interface |
| Power Requirements (typical) | 3.5 W |
| Housing Type | Box |
| Housing Size (L x W x H) | 29.3 mm x 29 mm x 29 mm |
| Weight | 80 g |
| Lens Mount | C-mount |
| Operating Temperature | 0 °C - 50 °C |
| Attribute Name | Attribute Value |
| Mount | C-mount |
| Focal Length | 12 mm |
| Working Distance | 100 mm |
| Type | Lens Accessory |
| Cable Length | 10 m |
| LED Color | Red |
| Peak Wavelength (typical) | 625 nm |
| Protection Class | IP54 |
| No. of Ports | 4 |
| Data Bandwidth (p.port; Total) | 5 Gbps (625 MB/s); 5 Gbps (625 MB/s) |
| Synchronization | free-run, hardware trigger, software trigger |
| Digital Output | 1 |
| General Purpose I/O | 2 |
Obtain a Quote for Basler Area Scan Camera with Color acA1600-20uc part no: 106220 at economical prices. Specifications Overview for acA1600-20uc, 106220 reveals Product Family offers the ace Classic and Standard series, featuring a 2 MP resolution at 20 fps. The camera utilizes a USB 3.0 interface and supports Power over Ethernet Via USB 3.0 interface power supply options. Designed for durability, the camera is housed in a robust Box-type enclosure with a C-mount lens interface. It operates efficiently within a temperature range of 0 °C - 50 °C making it suitable for various industrial environments. The focal length is 12 mm with a working distance of 100 mm and a cable length of 10 m. The camera operates at a peak wavelength of 625 nm. Take the First Step with a Quote for your requirement of Basler Area Scan Camera with Color. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
