a2A4200 (GMAX2509): 108358 - Basler 4200 px X 2160 px Resolution (H x V) Vision
Technical Specifications of Basler 4200 px X 2160 px Resolution (H x V) Vision a2A4200 (GMAX2509) 108358:
| Product Family | ace 2 R |
| Frame rate | 12 fps |
| Interface | GigE |
| Pixel Bit Depth | 8 bits, 10 bits, 12 bits |
Basler 4200 px X 2160 px Resolution (H x V) Vision a2A4200 (GMAX2509), 108358 Technical Specifications:
| Specification | Value |
|---|---|
| Product Family | ace 2 R |
| Camera Category | Area Scan Camera |
| Sensor Vendor | Gpixel |
| Sensor | GMAX2509 |
| Shutter | Global Shutter |
| Sensor Format | 1.1" |
| Sensor Diagonal | 11.8 mm |
| Sensor Type | CMOS |
| Sensor Size | 10.52 mm × 5.42 mm |
| Resolution (H x V) | 4200 px × 2160 px |
| Resolution | 9.1 MP |
| Pixel Size (H x V) | 2.5 μm × 2.5 μm |
| Frame rate | 12 fps |
| Mono/Color | Mono |
| Spectrum | Visible |
| Quantum Efficiency (typical/minimal) | 52.7 % (typical) |
| Dark Noise (typical/maximal) | 1.1 e¯ (typical) |
| Saturation Capacity (typical/minimal) | 4.6 ke¯ (typical) |
| Dynamic Range (typical/minimal) | 68.8 dB (typical) |
| Signal-to-Noise Ratio (typical/minimal) | 36.7 dB (typical) |
| Interface | GigE |
| Image Data Interface | Fast Ethernet (100 Mbit/s), Gigabit Ethernet (1000 Mbit/s) |
| Pixel Bit Depth | 8 bits, 10 bits, 12 bits |
| Exposure Control | hardware trigger, programmable via the camera API |
| Digital Input | 1 |
| Power Supply | PoE or 12-24 VDC |
| Power Requirements (typical) | 3.4 W |
| Housing Type | Box |
| Housing Size (L x W x H) | 55.5 mm x 29 mm x 29 mm |
| Weight | 100 g |
| Lens Mount | C-mount |
| Operating Temperature | -10 °C - 60 °C |
| Attribute Name | Attribute Value |
| Mount | C-mount |
| Focal Length | 12 mm |
| Working Distance | 100 mm |
| Type | Lens Accessory |
| Cable Length | 5 m |
| LED Color | Red |
| Peak Wavelength (typical) | 625 nm |
| Protection Class | IP54 |
| Product Line | Standard |
| No. of Ports | 4 |
| Data Bandwidth (p.port; Total) | 1 Gbps; 4 Gbps |
| Power Consumption PoE | 4.8 W |
Call us for Basler 4200 px X 2160 px Resolution (H x V) Vision a2A4200 (GMAX2509) part no: 108358 at the best rates. Technical Attributes of a2A4200 (GMAX2509), 108358 are ace 2 R Sensor Product Family offers a cutting-edge 9.1 MP resolution at an impressive 12 fps utilizing the GigE interface. It supports 8 bits, 10 bits, 12 bits pixel depth, ensuring high-quality imaging. Power is supplied via PoE or 12-24 VDC, making it efficient and easy to integrate. The robust Box-type housing is designed to withstand industrial conditions, with an C-mount lens interface for versatile application. Operating temperatures range from -10 °C - 60 °C making it reliable in various environments. The system is equipped with a 12 mm focal length lens, a working distance of 100 mm and a cable length of 5 m providing flexibility for different setups. The sensor operates at a peak wavelength of 625 nm. Unlock Exclusive Pricing with a Quote for your requirement of Basler 4200 px X 2160 px Resolution (H x V) Vision. Trust in our ability to provide more advantageous pricing and dedicated support beyond other other Dealers.
