a2A2840 (IMX487 UV): 109237 - Basler 11 mm Sensor Diagonal Vision System
Technical Specifications of Basler 11 mm Sensor Diagonal Vision System a2A2840 (IMX487 UV) 109237:
| Product Family | ace 2 X |
| Frame rate | 14 fps |
| Interface | GigE |
Basler 11 mm Sensor Diagonal Vision System a2A2840 (IMX487 UV), 109237 Technical Specifications:
| Specification | Value |
|---|---|
| Product Family | ace 2 X |
| Camera Category | Area Scan Camera |
| Sensor Vendor | Sony |
| Sensor | IMX487 |
| Shutter | Global Shutter |
| Sensor Format | 2/3" |
| Sensor Diagonal | 11 mm |
| Sensor Type | CMOS |
| Sensor Size | 7.78 mm × 7.78 mm |
| Resolution (H x V) | 2856 px × 2848 px |
| Resolution | 8.1 MP |
| Pixel Size (H x V) | 2.74 μm × 2.74 μm |
| Frame rate | 14 fps |
| Mono/Color | Mono |
| Spectrum | UV |
| Interface | GigE |
| Image Data Interface | Fast Ethernet (100 Mbit/s), Gigabit Ethernet (1000 Mbit/s) |
| Synchronization | free-run, hardware trigger, software trigger |
| Exposure Control | hardware trigger, programmable via the camera API |
| Digital Input | 1 |
| General Purpose I/O | 2 |
| Power Supply | PoE or 12-24 VDC |
| Power Requirements (typical) | 3.2 W |
| Housing Type | Box |
| Housing Size (L x W x H) | 55.5 mm x 29 mm x 29 mm |
| Weight | 100 g |
| Lens Mount | C-mount |
| Operating Temperature | 0 °C - 50 °C |
| Attribute Name | Attribute Value |
| Mount | C-mount |
| Focal Length | 25 mm |
| Working Distance | 155 mm |
| Type | Data Cable |
| Cable Length | 25 m |
| LED Color | Ultraviolet (UV) |
| Peak Wavelength (typical) | 365 nm |
| Protection Class | IP65 |
| No. of Ports | 4 |
| Data Bandwidth (p.port; Total) | 1 Gbps; 4 Gbps |
| Housing Alternatives | none |
| Useful Range (min/max) | 335 nm - 400 nm |
| Bandwidth FWHM | 80 nm |
| Filter Thread | M30.5 x 0.5 |
Obtain a Quote for Basler 11 mm Sensor Diagonal Vision System a2A2840 (IMX487 UV) part no: 109237 at economical prices. Specifications Overview for a2A2840 (IMX487 UV), 109237 reveals ace 2 X Sensor Product Family offers a cutting-edge 8.1 MP resolution at an impressive 14 fps utilizing the GigE interface. It supports pixel depth, ensuring high-quality imaging. Power is supplied via PoE or 12-24 VDC, making it efficient and easy to integrate. The robust Box-type housing is designed to withstand industrial conditions, with an C-mount lens interface for versatile application. Operating temperatures range from 0 °C - 50 °C making it reliable in various environments. The system is equipped with a 25 mm focal length lens, a working distance of 155 mm and a cable length of 25 m providing flexibility for different setups. The sensor operates at a peak wavelength of 365 nm. Take the First Step with a Quote for your requirement of Basler 11 mm Sensor Diagonal Vision System. Our commitment to better pricing and exceptional support sets us apart from other Competitors.
