Bannerengineering ZMX-3DE2500HF-Q7 - 3D Time of Flight Sensor
Technical Specifications of Banner 3D Time of Flight Sensor ZMX-3DE2500HF-Q7:
| Max Sensing Distance (mm) | 2500 |
| NEMA / UL Type Rating | NEMA 4X |
| Input Output | Discrete |
| Power Supply | 12-30 V dc |
Bannerengineering 3D Time of Flight Sensor ZMX-3DE2500HF-Q7 Technical Specifications
| Specification | Value |
|---|---|
| Type | ZMX Series |
| Housing Style | Rectangular |
| Sensing Mode (General) | Proximity |
| Sensing Mode (Detailed) | Time of Flight |
| IP Rating | IP65 |
| NEMA / UL Type Rating | NEMA 4X |
| Sensing Beam | Infrared Laser |
| Power | DC |
| Primary Housing Material | Aluminum |
| Input Output | Discrete |
| Max Sensing Distance (mm) | 2500 |
| Connection | Integral QD |
| Number of Pins | 4 |
| Adjustments | Software |
| Quick Disconnect Type | M8 |
| Feature: Quick Disconnect | Yes |
| Device Type | Sensor |
| Power Supply | 12-30 V dc |
| Minimum Sensing Distance (mm) | 200 |
| Discrete (Switched) Outputs | 2 NPN/PNP Configurable |
| Max Operating Temperature (°C) | 50 |
| Min Operating Temperature (°C) | -10 |
| Minimum Response Time (ms) | 150 |
| Laser Classification | Class 1 |
| PFM Output | Yes |
| Max Ambient Light (Lux) | 10000 |
| Radar Beam Pattern (H x V °) | 60 x 45 |
| PC Configurable | Yes |
| Common Ethernet Protocol | Yes |
