Banner XS8SI Safety Relay

Name: Bannerengineering XS8SI
Brand: IndMALL
SKU: 77e0ddca3fa5
Rating: 4.7 (4 reviews)

The Banner XS8SI Safety Relay offers 3, rating, Screw terminal type. Manufactured by Banner under the Banner Safety Relay category, this model belongs to the ATK Series.

Datasheet

Power Consumption

0.07 A (no load); 0.23 A (full load)

Banner XS8SI Safety Relay – Technical Specifications

Specification	Value
Type	XS26 Series Expandable Safety Controllers
IP Rating	IP20
Device Type	Safety Controller
PL Rating	e
Recovery Time	250 (typical), 400 (max)
SIL Rating	3
Vibration	9-150 Hz at 1g occasional/0.5g continuous
LCD Display	No
In-Series Diagnostics	No
Max Operating Temperature ( °C)	55
Relative Humidity	90% @ 50° C
SISTEMA	PFHd = 4 x 10-10
Safety Module Type	Input Module
Expandable	Yes
Dimension (H x W x D in mm)	110 x 22.5 x 129
Input Operation	Simultaneous or Concurrent
Number of Safe Inputs	8
Input Configuration	Configurable
Safety Input - Dual Channel (Solid-State)	50 mA @ 15 - 30 V dc
Non Safe Output Rating	80 mA @ 24 V dc (individual) maximum; overcurrent protected
Splittable Safe Output	No
Power Consumption	0.07 A (no load); 0.23 A (full load)
Response Time (ms)	See Software Configuration Summary
Terminal Type	Screw
Removable Terminals	Yes
Safety Category Rating	4
E-Stops/Rope Pulls	Yes
Safety Mat	Yes
Motor Speed	No
Muting	Yes
Gate Switch (NC/NC) Input	Yes
Gate Switch (NC/NO) Input	Yes
Gate Switch (OSSD) Input	Yes
Light Curtains/Scanner with EDM Input	Yes
Light Curtains/Scanner without EDM Input	Yes
Non Safe Output Configuration	Up to 2 PNP
Number of Convertible Inputs	2
Safety Input - Dual Channel (Dry Contact)	5-50 mA @ 24 V dc
Safety Input - Reset	5-50 mA @ 24 V dc
THC Rating	IIIC
Safety Input - Single Channel	5-50 mA @ 24 V dc
Input Resistance	150 Ω max. per lead
Two-Hand Controls	Yes
