Banner XS1RO Safety Relay
The Banner XS1RO Safety Relay offers 3, rating, Screw terminal type. Manufactured by Banner under the Banner Safety Relay category, this model belongs to the ATK Series.
| Safe Output Rating | Relay - 2 NO: 6A; 1 NC: 2.5A |
| Power Consumption | 0.125 A (outputs on) |
Banner XS1RO Safety Relay – Technical Specifications
| Specification | Value |
|---|---|
| Type | XS26 Series Expandable Safety Controllers |
| IP Rating | IP20 |
| Device Type | Safety Controller |
| PL Rating | e |
| SIL Rating | 3 |
| Vibration | 9-150 Hz at 1g occasional/0.5g continuous |
| LCD Display | No |
| In-Series Diagnostics | No |
| Max Operating Temperature ( °C) | 55 |
| Relative Humidity | 90% @ 50° C |
| SISTEMA | PFHd = 7.6 x 10-10 |
| Safety Module Type | Output Module |
| Expandable | Yes |
| Dimension (H x W x D in mm) | 110 x 22.5 x 129 |
| Independently Controlled Safe Outputs | 1 |
| Output Configuration | 2 NO |
| Safe Output Rating | Relay - 2 NO: 6A; 1 NC: 2.5A |
| Splittable Safe Output | No |
| Mechanical Life (Operations in Millions) | 40 |
| Power Consumption | 0.125 A (outputs on) |
| Response Time (ms) | See Software Configuration Summary |
| Terminal Type | Screw |
| Removable Terminals | Yes |
| Electrical Life (Cycles @ VA) | 50,000 @ full resistive load |
| Safety Category Rating | 4 |
| Gate Switch (NC/NC) Input | No |
| Gate Switch (NC/NO) Input | No |
| Gate Switch (OSSD) Input | No |
| Light Curtains/Scanner with EDM Input | No |
| Light Curtains/Scanner without EDM Input | No |
| Non Safe Output Configuration | 1 NC |
