Banner WLS28PXRGBW850DXKQ Lighting and Indication

Name: Bannerengineering WLS28PXRGBW850DXKQ
Brand: Banner
SKU: WLS28PXRGBW850DXKQ
Rating: 4.7 (4 reviews)

The Banner WLS28PXRGBW850DXKQ Lighting and Indication offers a Linear Strip style, No Thread mounting, 18-30 V dc supply voltage, and Integral QD connection. Manufactured by Banner under the Banner Lighting and Indication category, this model belongs to the WLS28-2 Series.

Datasheet

Brand	Banner
Product Type	Lighting and Indication
Model Number	WLS28PXRGBW850DXKQ

Banner WLS28PXRGBW850DXKQ Lighting and Indication – Technical Specifications

Specification	Value
Housing Style	Linear Strip
IP Rating	IP50
Quick Disconnect Type	M12
Power	DC
Primary Housing Material	Aluminum
Connection	Integral QD
Indication	Yes
Mounting Thread	No Thread
Color Input Control	Communication Protocol
Number of Colors	Programmable
Product Size (mm)	28
Color Technology	RGB IO-Link
Color Option 1	RGBW
Animation Option 1	IO-Link Controlled
Supply Voltage	18-30 V dc
Physical Dimensions (LxWxH or DxH mm)	890.0 x 28.0 x 20.9
Environmental Rating	IP50
High Temperature (up to 100° C)	50
Min Op. Temperature (°C)	-40
Storage Temp (°C)	-40 to 70
