Banner WLS15PXRGB0640DSSQP Lighting and Indication
The Banner WLS15PXRGB0640DSSQP Lighting and Indication offers a Linear Strip style, Communication Protocol input type, 12-30 V dc supply voltage, and Pigtail QD connection. Manufactured by Banner under the Banner Lighting and Indication category, this model belongs to the Andon lights.
| Brand | Banner |
| Product Type | Lighting and Indication |
| Model Number | WLS15PXRGB0640DSSQP |
Banner WLS15PXRGB0640DSSQP Lighting and Indication β Technical Specifications
| Specification | Value |
|---|---|
| Housing Style | Linear Strip |
| IP Rating | IP66, IP67 |
| Cable Length (m) | 0.15 |
| Power | DC |
| Primary Housing Material | Polycarbonate |
| Connection | Pigtail QD |
| Feature: Audible | No |
| Display | No |
| Mounting Thread | No Thread |
| Color Input Control | Communication Protocol |
| Number of Colors | Programmable |
| Product Size (mm) | 15 |
| Color Technology | RGB Configurable |
| Color Option 1 | RGB |
| Animation Option 1 | Modbus Controlled |
| Quick Disconnect Type | M12 |
| Max Current Color (mA) | 500 |
| Wire Selectable Function | Programmable |
| Number of Input Pins/Conductors | 4 |
| Supply Voltage | 12-30 V dc |
| Input Type | Communication Protocol |
| Physical Dimensions (LxWxH or DxH mm) | 640.0 x 30.6 x 15.5 |
| Environmental Rating | IP66; IP67 |
| High Temperature (up to 100Β° C) | 50 |
| Min Op. Temperature (Β°C) | -40 |
| Primary Window Material | Polycarbonate Diffused |
| Multi-Color Device | Simultaneous Colors On |
| Feature: Quick Disconnect | Yes |
| Modbus RTU | Yes |
| Storage Temp (Β°C) | -40 to 70 |
| Secondary Material | Polyamide |
| Dimming Option | Modbus Controlled |
| Illuminated Length (LxWxH mm) | 566.4 |
