Banner UM-FA-9A Safety Relay
The Banner UM-FA-9A Safety Relay offers 3, rating, Screw terminal type. Manufactured by Banner under the Banner Safety Relay category, this model belongs to the ATK Series.
| Supply Voltage | 24 V ac/dc +/- 10% |
| Safe Output Rating | Relay - 6 A |
| Power Consumption | 2 W / 2 VA |
Banner UM-FA-9A Safety Relay β Technical Specifications
| Specification | Value |
|---|---|
| Type | UM Series Universal Input Safety Relays |
| IP Rating | IP20 |
| Power | AC/DC Universal |
| Supply Voltage | 24 V ac/dc +/- 10% |
| Device Type | Safety Relay |
| PL Rating | e |
| Recovery Time | 250 |
| SIL Rating | 3 |
| Vibration | 10-55 Hz at 0.35 mm |
| LCD Display | No |
| In-Series Diagnostics | No |
| Max Operating Temperature ( Β°C) | 50 |
| Relative Humidity | 90% @ 50Β° C |
| SISTEMA | PFHd = 5.0 x 10-10 |
| Safety Module Type | Universal Module |
| Expandable | No |
| Dimension (H x W x D in mm) | 84 x 22.5 x 118 |
| Input Operation | Simultaneous or Concurrent |
| Number of Safe Inputs | 1 |
| Input Configuration | 2 OSSD, 2 NC, or 1 NC |
| Safety Input - Dual Channel (Solid-State) | 5-20 mA @ 18-28 V dc (PNP) |
| Independently Controlled Safe Outputs | 1 |
| Output Configuration | 3 NO |
| Safe Output Rating | Relay - 6 A |
| Splittable Safe Output | No |
| Mechanical Life (Operations in Millions) | 20 |
| Power Consumption | 2 W / 2 VA |
| Response Time (ms) | 25 (typical) |
| Terminal Type | Screw |
| Removable Terminals | Yes |
| Electrical Life (Cycles @ VA) | 1,000,000 @ 450 VA |
| Safety Category Rating | 4 |
| E-Stops/Rope Pulls | Yes |
| Safety Mat | No |
| Motor Speed | No |
| Muting | No |
| Gate Switch (NC/NC) Input | Yes |
| Gate Switch (NC/NO) Input | No |
| Gate Switch (OSSD) Input | Yes |
| Light Curtains/Scanner with EDM Input | Yes |
| Light Curtains/Scanner without EDM Input | Yes |
| Safety Input - Dual Channel (Dry Contact) | 10-20 mA @ 12 V dc |
| Safety Input - Reset | 40-100 mA @ 24 V ac/dc +/- 10% |
| Safety Input - Single Channel | 40-100 mA @ 24 V ac/dc +/- 10% |
| Input Resistance | 100 Ξ© max. per channel |
| Recovery Time (ms) | 250 |
