Bannerengineering TLF100P3KCQP Tower Light
The Banner TLF100P3KCQP Tower Light offers Flat - Tower housing style, 3 No. of Colors, No Thread Mounting Method, and Pigtail QD connection. Manufactured by Banner under the Banner Tower Lights category, this model belongs to the TL Series.
| Housing Style | Flat - Tower |
| Supply Voltage | 18-30 V dc |
| Input Type | Communication Protocol |
Banner TLF100P3KCQP Tower Light – Technical Specifications
| Specification | Value |
|---|---|
| Type | TLF100 Pro Flush Mount Tower Light |
| Housing Style | Flat - Tower |
| IP Rating | IP65, IP69K |
| NEMA / UL Type Rating | UL 4X |
| Cable Length (m) | 0.15 |
| Power | DC |
| Primary Housing Material | Polycarbonate |
| Connection | Pigtail QD |
| Feature: Audible | No |
| Display | No |
| Indication | Yes |
| Mounting Thread | No Thread |
| Color Input Control | Communication Protocol |
| Number of Colors | 3 |
| Product Size (mm) | 100 |
| Color Technology | RGB IO-Link |
| Animation Option 1 | IO-Link Controlled |
| Quick Disconnect Type | M12 |
| Max Current Color (mA) | 150 |
| Number of Input Pins/Conductors | 4 |
| Supply Voltage | 18-30 V dc |
| Input Type | Communication Protocol |
| Max Input Response Time (ms) | 20 |
| Physical Dimensions (LxWxH or DxH mm) | 100.0 x 190.0 x 42.2 |
| Environmental Rating | IP65; IP69K |
| High Temperature (up to 100° C) | 50 |
| Min Op. Temperature (°C) | -40 |
| Primary Housing Color | Gray |
| Primary Window Material | Polycarbonate Diffused |
| Multi-Color Device | Simultaneous Colors On |
| Feature: Quick Disconnect | Yes |
| Max Current - Audible Alarm (mA) | 56 |
| Max Op. Relative Humidity Non-Condensing (%) | 95% @ 50°C |
| Dimming Option | Programmable |
| IO Link | Yes |
| Number of Tower Light Segments | 3 |
