Bannerengineering TL70B-GYRQ Tower Light

Name: Bannerengineering TL70B-GYRQ
Brand: IndMALL
SKU: TL70B-GYRQ
Rating: 4.7 (4 reviews)

The Banner TL70B-GYRQ Tower Light offers Base Mount - Tower housing style, 3 No. of Colors, M30 x 1.5 Mounting Method, and Integral QD connection. Manufactured by Banner under the Banner Tower Lights category, this model belongs to the TL Series.

Datasheet

Housing Style	Base Mount - Tower
Supply Voltage	12-30 V dc
Input Type	Bimodal (PNP/NPN)

Banner TL70B-GYRQ Tower Light – Technical Specifications

Specification	Value
Type	TL70 Basic Series 70mm Tower Lights
Housing Style	Base Mount - Tower
IP Rating	IP65
Power	DC
Primary Housing Material	Polycarbonate
Connection	Integral QD
Feature: Audible	No
Display	No
Indication	Yes
Mounting Thread	M30 x 1.5
Color Input Control	Individual (One wire/color, same number of colors as input wires)
Number of Colors	3
Product Size (mm)	70
Color Technology	Standard LED
Color Option 1	Green
Animation Option 1	Dip-Switch Controlled
Quick Disconnect Type	M12
Color Option 2	Yellow
Animation Option 2	Dip-Switch Controlled
Color Option 3	Red
Animation Option 3	Dip-Switch Controlled
Max Current Color (mA)	955
Number of Input Pins/Conductors	5
Supply Voltage	12-30 V dc
Input Type	Bimodal (PNP/NPN)
Max Input Response Time (ms)	2
Physical Dimensions (LxWxH or DxH mm)	70.0 x 311.3
Environmental Rating	IP65
High Temperature (up to 100° C)	50
Min Op. Temperature (°C)	-40
Primary Housing Color	Black
Primary Window Material	Polycarbonate Diffused
Multi-Color Device	Simultaneous Colors On
Feature: Quick Disconnect	Yes
Max Op. Relative Humidity Non-Condensing (%)	95% @ 50°C
Storage Temp (°C)	-40 to 70
Lumens Color 1	67
Color 1 - Wavelength/Color Temp/Coordinates	522 nm
Lumens Color 2	55
Color 2 - Wavelength/Color Temp/Coordinates	589 nm
Lumens Color 3	24
Color 3 - Wavelength/Color Temp/Coordinates	620 nm
Number of Tower Light Segments	3
