Banner TL50BLZGR2AOS3I Tower Light
The Banner TL50BLZGR2AOS3I Tower Light offers a M30 x 1.5 mounting, 2 No.of colors, 100-240 V ac supply voltage, and Cable connection. Manufactured by Banner under the Banner Tower Light category, this model belongs to the TL50 Series.
| Brand | Banner |
| Product Type | Tower Light |
| Model Number | TL50BLZGR2AOS3I |
Banner TL50BLZGR2AOS3I Tower Light β Technical Specifications
| Specification | Value |
|---|---|
| Power | AC |
| IP Rating | IP67 |
| Display | No |
| NEMA / UL Type Rating | NEMA 13 |
| Housing Style | Base Mount - Tower |
| Primary Housing Material | ABS |
| Indication | Yes |
| Mounting Thread | M30 x 1.5 |
| Color Input Control | Individual (One wire/color, same number of colors as input wires) |
| Number of Colors | 2 |
| Product Size (mm) | 50 |
| Color Technology | Standard LED |
| Number of Tower Light Segments | 3 |
| Color Option 1 | Green |
| Animation Option 1 | Solid On |
| Connection | Cable |
| Quick Disconnect Type | - |
| Lumens Color 1 | 52 |
| Color 1 - Wavelength/Color Temp/Coordinates | 525 nm |
| Color Option 2 | Red |
| Animation Option 2 | Flashing Only |
| Lumens Color 2 | 24 |
| Color 2 - Wavelength/Color Temp/Coordinates | 626 nm |
| Color Option 3 | - |
| Animation Option 3 | - |
| Lumens Color 3 | - |
| Color 3 - Wavelength/Color Temp/Coordinates | - |
| Color Option 4 | - |
| Animation Option 4 | - |
| Lumens Color 4 | - |
| Color 4 - Wavelength/Color Temp/Coordinates | - |
| Max Current Color (mA) | 55 |
| Number of Input Pins/Conductors | 4 |
| Supply Voltage | 100-240 V ac |
| Input Type | AC |
| Max Input Response Time (ms) | 500 |
| Physical Dimensions (LxWxH or DxH mm) | 50.0 x 227.7 |
| Environmental Rating | IP67 |
| Max Op. Relative Humidity Non-Condensing (%) | 95% @ 50Β°C |
| High Temperature (up to 100Β° C) | 50 |
| Min Op. Temperature (Β°C) | -20 |
| Storage Temp (Β°C) | -40 to 70 |
| Primary Housing Color | Black |
| Primary Window Material | Polycarbonate Clear |
| Indication Intensity | High Brightness & Daylight Visible |
| Multi-Color Device | Simultaneous Colors On |
