Banner TL505ALSKQ Tower Light
The Banner TL505ALSKQ Tower Light offers a Base Mount - Tower housing style, 5 No.of colors, 18-30 V dc supply voltage, Communication Protocol input type, and Integral QD connection. Manufactured by Banner under the Banner Tower Light category, this model belongs to the TL50 Series.
| Brand | Banner |
| Product Type | Tower Light |
| Model Number | TL505ALSKQ |
Banner TL505ALSKQ Tower Light β Technical Specifications
| Specification | Value |
|---|---|
| Power | DC |
| IP Rating | IP67 |
| Display | No |
| NEMA / UL Type Rating | NEMA and UL 13 |
| Housing Style | Base Mount - Tower |
| Primary Housing Material | ABS |
| Indication | Yes |
| Mounting Thread | M30 x 1.5 |
| Color Input Control | Communication Protocol |
| Number of Colors | 5 |
| Product Size (mm) | 50 |
| Color Technology | RGB IO-Link |
| Number of Tower Light Segments | 6 |
| Color Option 1 | RGB |
| Animation Option 1 | Programmable |
| Connection | Integral QD |
| Quick Disconnect Type | M12 |
| Max Current Color (mA) | 100 |
| Dimming Option | Programmable |
| Number of Input Pins/Conductors | 4 |
| Supply Voltage | 18-30 V dc |
| Audible Alarm Type | Continuous |
| Input Type | Communication Protocol |
| Max Audible Intensity (db at 1m) | 94 |
| Min Audible Intensity (db at 1m) | 74 |
| Audible Operating Frequency (kHz) | 2.9 |
| Max Input Response Time (ms) | 20 |
| Max Current - Audible Alarm (mA) | 35 |
| Physical Dimensions (LxWxH or DxH mm) | 50.0 x 305.2 |
| Environmental Rating | IP67 |
| Max Op. Relative Humidity Non-Condensing (%) | 95% @ 50Β°C |
| High Temperature (up to 100Β° C) | 50 |
| Min Op. Temperature (Β°C) | -20 |
| Primary Housing Color | Black |
| Primary Window Material | Polycarbonate Diffused |
| Cable Length (m) | - |
