Banner STP-M12-806 BSZ Cordset
The Banner STP-M12-806 BSZ Cordset offers a Double Ended, M12 connection, 42 V ac/dc rating, and Shield - Tied to Coupling Nut. Manufactured by Banner under the Banner Cordset category.
| Brand | Banner |
| Product Type | Cordsets |
| Model Number | STP-M12-806 BSZ |
Banner STP-M12-806 BSZ Cordset – Technical Specifications
| Specification | Value |
|---|---|
| IP Rating | IP67 |
| Cable Jacket Color | Black |
| Connector 1 Key Code | A |
| Cable Jacket Material | PVC |
| Coupling Nut Material | Nickel Plated Brass |
| Connector 1 Gender | Male |
| Connector 1 Orientation | Straight |
| Cordset Length (m) | 1.83 |
| Outside Cable Diameter (mm) | 6.2 |
| Connector 1 Number of Contacts | 8 |
| Number of Ends | Double Ended |
| Connector 2 Type | RJ45 |
| Connector 1 Type | M12 |
| Voltage Rating (V) | 42 V ac/dc |
| Minimum Temp. (Celsius) | -40 |
| Shield/No Shield | Shield - Tied to Coupling Nut |
| Overmold Material and Color | PUR Black |
| Current Rating (A) | 0.5 |
| Maximum Temp. (Celsius) | 105 |
| Cordset Length Range (m) | Less than 2.00 |
| Connector 2 Number of Contacts | 8 |
| Connector 2 Gender | Male |
| Connector 2 Orientation | Straight |
