Bannerengineering SSA-EBM-02E - Illuminated E-Stop Buttons
Technical Specifications of Banner Illuminated E-Stop Buttons SSA-EBM-02E:
| Spec | Value |
|---|
| Actuation | Twist-to-Release |
| Contact Rating | 2 A @ 24 V dc |
| Button Diameter (mm) | 40 |
| IP Rating | IP65 |
Bannerengineering SSA-EBM-02E Illuminated E-Stop Buttons Technical Specifications
| Specification | Value |
|---|
| IP Rating | Panel Mount Emergency Stop Button |
| Primary Housing Material | Polycarbonate |
| Device Type | Push Button |
| Actuation | Twist-to-Release |
| Connection Type | Screw Terminal |
| Button Shroud | No |
| In-Series Diagnostics | No |
| Actuator/Button Material | Thermoplastic |
| Contact Quantity | 2 NC |
| Mounting Thread/Style | Flat |
| Contact Rating | 2 A @ 24 V dc |
| Dimensions (HxWxD mm ) | 105 x 70 x 70 |
| Min Operating Temperature ( °C) | -25 |
| Button Diameter (mm) | 40 |
| Max Operating Temperature ( °C) | 60 |
