Banner SSA-EB1PLXR-02ECQ5A Lighting and Indication

Name: Bannerengineering SSA-EB1PLXR-02ECQ5A
Brand: Banner
SKU: SSA-EB1PLXR-02ECQ5A
Rating: 4.9 (4 reviews)

The Banner SSA-EB1PLXR-02ECQ5A Lighting and Indication offers a 30 mm Mount Emergency Stop Buttons type, 30 mm mounting, 40 mm button diameter, and M12 connection. Manufactured by Banner under the Banner Lighting and Indication category, this model belongs to the Andon lights.

Datasheet

Brand	Banner
Product Type	Lighting and Indication
Model Number	SSA-EB1PLXR-02ECQ5A

Banner SSA-EB1PLXR-02ECQ5A Lighting and Indication – Technical Specifications

Specification	Value
Type	30 mm Mount Emergency Stop Buttons
IP Rating	IP65
Primary Housing Material	Polycarbonate
Connection	Integral QD
Device Type	Push Button
Actuation	Twist/Pull-to-Release
Mounting Thread	30 mm
Connection Type	M12
Armed Color (Solid)	OFF
Actuated Color	Red - Flash
Illumination Type	Base
Contact Quantity	2 NC
Contact Rating	2 A @ 24 V dc
Button Diameter (mm)	40
Physical Dimensions (LxWxH or DxH mm)	120 x 80
High Temperature (up to 100° C)	55
Min Op. Temperature (°C)	-25
