Banner SSA-EB1PLGR-12ED1 Lighting and Indication
The Banner SSA-EB1PLGR-12ED1 Lighting and Indication offers a Flush-Mount Emergency Stop Button type, Flat mounting, 40 mm button diameter, and Terminal Strip connection. Manufactured by Banner under the Banner Lighting and Indication category, this model belongs to the Andon lights.
| Brand | Banner |
| Product Type | Lighting and Indication |
| Model Number | SSA-EB1PLGR-12ED1 |
Banner SSA-EB1PLGR-12ED1 Lighting and Indication β Technical Specifications
| Specification | Value |
|---|---|
| IP Rating | Flush-Mount Emergency Stop Button |
| Primary Housing Material | Polycarbonate |
| Device Type | Push Button |
| Actuation | Twist/Pull-to-Release |
| Connection Type | Terminal Strip |
| Armed Color (Solid) | Green |
| Button Shroud | No |
| Actuated Color | Red - Flash |
| Illumination Type | Base |
| In-Series Diagnostics | No |
| Feature: Illuminated | Yes |
| Actuator/Button Material | Thermoplastic |
| Contact Quantity | 2 NC, 1 NO |
| Mounting Thread/Style | Flat |
| Contact Rating | 2 A @ 24 V dc |
| Dimensions (HxWxD mm ) | 103 x 110 x 81 |
| Min Operating Temperature ( Β°C) | -25 |
| Stop Signal Color ( Solid) | Red |
| Button Diameter (mm) | 40 |
| Max Operating Temperature ( Β°C) | 55 |
