Banner SSA-EB1P-22 Lighting and Indication
The Banner SSA-EB1P-22 Lighting and Indication offers a Panel Mount Emergency Stop Button type, Panel mounting, 40 mm button diameter, and Screw Terminal connection. Manufactured by Banner under the Banner Lighting and Indication category, this model belongs to the Andon lights.
| Brand | Banner |
| Product Type | Lighting and Indication |
| Model Number | SSA-EB1P-22 |
Banner SSA-EB1P-22 Lighting and Indication – Technical Specifications
| Specification | Value |
|---|---|
| Type | Panel Mount Emergency Stop Button |
| IP Rating | IP65 |
| Primary Housing Material | Polycarbonate |
| Device Type | Push Button |
| Actuation | Twist/Pull-to-Release |
| Mounting Thread | Panel |
| Connection Type | Screw Terminal |
| Contact Quantity | 2 NC, 2 NO |
| Contact Rating | 2 A @ 24 V dc |
| Button Diameter (mm) | 40 |
| Physical Dimensions (LxWxH or DxH mm) | 81 x 37 x 40 |
| High Temperature (up to 100° C) | 60 |
| Min Op. Temperature (°C) | -25 |
