In most procurement cycles, BANNERENGINEERING-SSA-EB1P-11-ESPL1-30-60 is considered with Banner Photoelectric Sensor, Banner Bannerengineering Pvs28D100Qp and Banner Safety Light Curtain Type 4 S4B, giving decision-makers confidence that theyβve chosen the most dependable component.
Banner SSA-EB1P-11-ESPL1-30/60 Lighting and Indication
The Banner SSA-EB1P-11-ESPL1-30/60 Lighting and Indication offers a Panel Mount Emergency Stop Button type, Panel mounting, 40 mm button diameter, and Wiring Chamber connection. Manufactured by Banner under the Banner Lighting and Indication category, this model belongs to the Andon lights.
| Brand | Banner |
| Product Type | Lighting and Indication |
| Model Number | SSA-EB1P-11-ESPL1-30/60 |
Banner SSA-EB1P-11-ESPL1-30/60 Lighting and Indication β Technical Specifications
| Specification | Value |
|---|---|
| IP Rating | Panel Mount Emergency Stop Button |
| Primary Housing Material | Polycarbonate |
| Device Type | Push Button |
| Actuation | Twist/Pull-to-Release |
| Connection Type | Wiring Chamber |
| Button Shroud | No |
| Actuator/Button Material | Zinc Alloy Die-Cast |
| Contact Quantity | 1 NC, 1 NO |
| Mounting Thread/Style | Panel |
| Dimensions (HxWxD mm ) | 81 x 37 x 40 |
| Min Operating Temperature ( Β°C) | -25 |
| Button Diameter (mm) | 40 |
| Max Operating Temperature ( Β°C) | 60 |
